Programming with SPM
The Boards option is also available in surrogate mode. In surrogate mode, you
can assign trunk and station modules (boards) to slots, even though those
boards have not actually been installed. Such boards are referred to as
"phantom boards" or "null boards."
NOTE:
If you assign phantom boards, they must be installed in higher slot numbers
than any real boards you assign. If you assign a phantom board to a lower
slot number than a real board, the control unit will not recognize the real
board(s) that follow the phantom board.
The following boards can be selected:
Board
Type
400LSR
400GLR
800LS
800GLS
408LSA
408GLR
008ATL
008MLX
012TR/OPT
800DID
400E&M
100D
408GLM
The Inspect function (
assigned to slots on the control unit. Note that phantom boards as well as real
boards are displayed with the Inspect function; to see phantom board
assignments, you must print the System Information report (System –> More –>
Print –> SysSet-up).
You cannot use this option to change a board type. All boards assigned with
the Boards option, including phantom boards, are cleared (unassigned), if you
perform a Board Renumber (System –> Board Renum).
Description
4 loop-start line jacks with 4 touch tone receivers
4 ground-start loop-start line jacks with 4 touchtone
receivers
8 loop-start line jacks
8 ground-start/loop-start line jacks
4 loop-start line jacks and 8 ATL station jacks
4 ground-start loop-start line jacks and 8 ATL station jacks
8 ATL station jacks
8 MLX station jacks (16 endpoints)
12 tip/ring station jacks with 2 touchtone receivers or
008 OPT jacks
8 DID trunk jacks with 2 touchtone receivers
4 E&M tie trunk jacks
1 DS1 jack (24 channels)
4 ground-start loop-start line jacks and 8 MLX station
jacks (16 endpoints)
[ PgDn ]
) lets you see which modules have been
2-17
Using SPM
