Programming Procedures
Call Pickup Groups
Use this procedure to assignor remove a telephone from a call pickup group,
consisting of telephone users who can answer one another's calls by pressing a
button or by dialing a code.
A maximum of 30 call pickup groups with a maximum of 15 telephones per
group are allowed. A telephone can belong to only one group.
Before reassigning a telephone to a new group,
current group.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press
on the PC before saving your entry or menu selection.
Summary Call Pickup Groups
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
3-364 Call Pickup Groups
Sys Program
Exit
[F1]
press any key
System manager
All
Not required
Form 6d, Group Coverage
Not applicable
Call pickup group number, extension number
Yes
No
Extensions
Call Pickup
no.
Enter
Dial ext. no.
Exit
E x i t
[F6]
[F9]
Type pickup group no.
[F10]
[F5]
ext. no.
must remove it from its
YOU
[F5]
Dial pickup group
Enter
Enter
[F10]
[F5]
Type
