AT&T MERLIN LEGEND Release 2.0 System Programming Manual page 628

Programming Procedures
Display/Instructions
Step
x = option name selected in Step 4
Specify the table (nn = 1-18)
and route (m = 1-6) numbers
for Subpattern A or B (if you
are programming a sequence,
enter the lowest number).
Save your entry.
ARS Pool Table xx Route x:
Select capability
Voice Only
Data Only
Voice/Data
E x i t
xx = table number entered in Step 5
x = route numbef entered in Step 5
Select the appropriate
capability.
To specify other entries for
specified Subpattern
If next route number is
sequential
Your previous entry is saved
and the next route number is
shown on line 1 of screen
shown in Step 5.
If next route number is
not sequential
To save your entry when all
entries are complete
To return to System
Programming menu
On the console
Dial [nnm].
Select Enter.
E n t e r
Select Voice Only,
Data Only, or
Voice/Data.
Select Next.
Repeat Step 7.
Select Enter.
Repeat Steps 3-7.
Select Enter.
Select Exit
two times.
On the PC
Type [nnm]
[F10]
Press
[F1], [F2],
Press
[ F 3 ]
[F9]
Press
Repeat Step 7.
[F10]
Press
Repeat Steps 3-7.
[F10]
Press
[F5]
Press
two times.
Voice and/or Data Routing
or
3-537
