Programming Procedures
Disconnect Time
Use this procedure to specify the DID trunk disconnect time in milliseconds
NOTE:
DID trunks apply only in Hybrid/PBX mode.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press on the PC before saving your entry or menu selection.
Summary: Disconnect Time
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
Disconnect Time
3-156
Sys Program
Exit
[F1]
press any key
System manager
Hybrid/PBX
Not required
Form 3d, Incoming Trunks - DID
500 ms
10-2400 ms, in increments of 10 ms
No
Yes
LinesTrunks DID
Enter Drop Dial no. of ms
Exit
[F4] [F4] [F3]
[Alt] [P]
+ Type no. of ms
[F5]
Disconnect Dial trunk no.
Enter
[F10]
Type trunk no.
[F10] [F5]
Exit
[F5]
