AT&T MERLIN LEGEND Release 2.0 System Programming Manual page 498

Programming Procedures
Group Calling External Alert for Calls-In-Queue
Alarms
Use this procedure to designate the external alert device used to notify calling
group members when the number of calls in the queue reaches the
programmed threshold.
Only one external alert device can be designated for each calling group.
Since the external alert signal is continuous, it is recommended that only lamp-
type external alert devices be designated for use for the Calls-in-Queue alarm.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press on the PC before saving your entry or menu selection.
Summary: Group Calling External Alert for Calls-In-Queue Alarms
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
Sys Program
press any key
System manager
All
Not required
Form 6e, Group Calling
Not applicable
Extension number
No
No
Extensions
Alert Dial calling group ext. no.
Dial ext. no. for alert
[F6] [PgUp]
[F10]
ext. no.
[F10] [F5]
Group Calling External Alert for Calls-In-Queue Alarms
Exit
[F1] [F5]
More Grp Calling
Enter Exit
[F4] [F7]
Type calling group
[Alt] [P]
+ Type ext. no. for alert
[F5]
Xtnl
Enter Drop
Exit
3-407
