Programming Procedures
Other Digits
Use this procedure to specify extra digits that must be added by the system to
the beginning of the number dialed by the caller when calls are placed on an
identified route.
NOTE:
Pool routes must be programmed before you assign other digits.
A maximum of 20 digits can be added, in any combination of the digits 0
through 9.
Special characters such as switchhook flash, stop, and # cannot be included
as extra digits. Pause is allowed, except in the first position.
Other digits are assigned to Tables 1 through 18.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press
on the PC before saving your entry or menu selection.
Summary: Other Digits
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
3-524 Other Digits
Sys Program
Exit
[F1]
press any key
System manager
Hybrid/PBX
Not required
Form 9b, Automatic Route Selection Tables
0
20 digits (0 - 9)
No
No
Tables
ARS
Sub A Digit / More and Sub B
Digit
Dial table no. and pool route no.
Drop
Dial digits to be added
E x i t
[F8]
[F6]
[F7]/[PgUp]
no. and pool route no.
[F10]
digits to be added
[F5]
Enter
Enter
Exit
[F3]
and
Type table
[F10]
[Alt]
[P]
+
[F5]
[F5]
Type
