Programming Procedures
Signaling Mode
Use this procedure to specify the signaling for the 100D module as robbed-bit
or common-channel signaling.
NOTE:
This procedure is needed only for T1 facilities; signaling is set automatically
for PRI facilities.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press
Summary: Signaling Mode
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
Signaling Mode
3-112
Sys Program
press any key
on the PC before saving your entry or menu selection.
System manager
A l l
100D module idle
Form 3b, Incoming Trunks - DS1 Connectivity (100D
Module)
Robbed bit
Robbed Bit, Common Channel
No
No
LinesTrunks
Signaling
Exit
Exit
[F4]
[F1]
Select type of signaling
Exit
[F1]
[F5]
LS/GS/DS1
Dial SIot no.
Select type of signaling
[F10]
Type slot no.
[F10]
Enter
Enter
[F4]
[F5]
[F5]
