AT&T MERLIN LEGEND Release 2.0 System Programming Manual page 351

Programming Procedures
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press on the PC before saving your entry or menu selection.
Summary: Assign Intercom or System Access Buttons
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
3-260 Assign Intercom or System Access Buttons
Sys Program
Exit
[F1]
press any key
System manager
All, but note differences in factory settings
Telephone idle
Form 4b, Analog Multiline Telephone
Form 4d, MLX Telephone
Form 4e, MFM Adjuncts — MLX Telephone
Form 4f, Tip/Ring Equipment
Form 5a, Direct-Line Console (DLC) - Analog
Form 5b, Direct-Line Console (DLC) - Digital
Form 5c, MFM Adjunct (DLC)
Data Form 2a, Analog Data Station
Data Form 2b, Digital Data Station
Key Mode: An Intercom Ring, an Intercom Voice, and
the first eight lines connected to the system are
assigned to all analog multiline and MLX telephones,
excluding operator positions. Two Intercom Ring
buttons are assigned to tip/ring equipment connected
on an 012 module. An Intercom Ring and an Intercom
Originate Only (Ring) button are assigned to tip/ring
equipment connected by an MFM. No outside lines are
assigned,
Behind Switch Mode: An Intercom Ring, an Intercom
Voice, and a Prime Line button are assigned to all
analog multiline and MLX telephones, excluding
operator positions. Two Intercom Ring buttons and a
Prime Line button are assigned to tip/ring equipment
connected on an 012 module. An Intercom Ring and
an Intercom Originate Only (Ring) button are assigned
to tip/ring equipment connected by an MFM. No
outside lines are assigned.
[F5]
