AT&T MERLIN LEGEND Release 2.0 System Programming Manual page 232

Programming Procedures
Step Display/Instructions
To specify a single line, do the
following:
1. Specify entry mode.
2. Enter the number of the
trunk with remote dial
signaling.
3. To add or remove trunk
with remote dial
signaling
To specify a block of lines, do
the following:
1.
Select the tie trunks
associated with the 20
line buttons on the
system programming
console.
2. Specify remote or local
dial tone.
The green LED indicates the
following.
on = remote dial tone
off = local dial tone
To return to System
Programming menu
On the console
Select Entry Mode.
Dial [nnn].
Select Enter or
Delete.
Select Lines 01-20,
Lines 21–40, Lines
41–60,0r Lines 61-
80.
Toggle the LED
On/Off, as required.
Select Exit three
times.
Tie Trunk Dial Tone
On the PC
[F6]
Press
Type [nn].
[F10] [F8]
Press or
[F1], [F2],
Press
[F3], [F4]
or
Toggle the letter G
On/Off, as required.
[F5]
Press three times.
3-141
