AT&T MERLIN LEGEND Release 2.0 System Programming Manual page 293

Programming Procedures
T316 Timer – times the delay in network response when the system
sends a restart message to clear a B-channel
NOTE:
If you enter an invalid timer value, the number you enter is truncated to the
closest valid value. For example, if you enter 45 for a counter that ranges
from 0-30, 4 is recorded.
The following table shows the factory setting for each timer and counter and the
valid range for each threshold.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press
Summary Timers and Counters
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Timers and Counters
3-202
Sys Program
press any key
on the PC before saving your entry or menu selection.
System manager
All
Not required
Form 3b, Incoming Trunks — DS1 Connectivity (100D
Module)
See Table 3-2
Timer/Counter Setting
T200 Timer
T203 Timer
N200 Counter
N201 Counter
K Counter
T303 Timer
T305 Timer
T308 Timer
T309 Timer
T310 Timer
T313 Timer
T316 Timer
Exit
[F1] [F5]
Table 3-2. Timers and Counters
Factory Setting
Maximum response time 1 second
Maximum time 30 seconds
Maximum transmissions 3 transmissions
Maximum octets 260 octets
Maximum outstanding 7 frames
l-frames
Setup timeout 4 seconds
Disconnect timeout 4 seconds
Release timeout 4 seconds
Signal loss 90 seconds
10 seconds
Call Proc. timeout
4 seconds
Connect timeout
120 seconds
Restart timeout
Valid Range
1000 - 3000 ms
1-60 seconds
1 – 5 transmissions
16-260 octets
1-15 frames
4-12 seconds
4-30 seconds
4-12 seconds
30-120 seconds
2-10 seconds
4-12 seconds
30-120 seconds
