AT&T MERLIN LEGEND Release 2.0 System Programming Manual page 325

Programming Procedures
Call by Call Service Table
When a call is placed on a Call by Call B-channel group, a specific service is
selected, depending on the match between the dialed digits and the table
entries. A service must be specified, otherwise the entry is ignored. The Call
by Call table can contain up to 10 entries; each entry can contain up to 10
patterns, each with a maximum of eight digits. If a dialed number matches two
patterns, the longer pattern takes precedence That is, 212555 matches both
212555 and 212; however, the longer pattern is deemed the matching pattern.
In addition to patterns, the Call by Call table can specify from 0 through 8 digits
to be deleted (the default is 0).
If the last entry in the table is empty (no pattern is specified), this entry is used
as a default and matches any pattern and type of call.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press on the PC before saving your entry or menu selection.
Summary: Call by Call Service Table
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
3-234 Call by Call Service Table
Sys Program
Exit
[F1]
press any key
System manager
All
Not required
Form 3b, Incoming Trunks - DS1 Connectivity (100D
Module)
Not applicable
Pattern — up to eight digits
— voice, data, both
Call Type
— AT&T Toll, Local, Misc.
Service
Delete Digits — 0-8
No
No
[F5]
