Programming Procedures
Start and Stop Times for Subpatterns
Use this procedure to specify the time of day when calls are routed using
Subpattern B routing information.
Subpatterns are used to provide two different routing patterns according to the
time of day. This allows you to take advantage of lower rates that may apply to
some or all lines or to change restrictions on some facilities during off hours.
The stop time for Subpattern B is the start time for Subpattern A.
Enter times in 4-digit, 24-hour notation, using leading zeros as necessary.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press on the PC before saving your entry or menu selection.
Summary: Start and Stop Times for Subpatterns
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
Sys Program
Exit
[F1]
press any key
System manager
Hybrid/PBX
Not required
Form 9b, Automatic Route Selection Tables
Form 9c, Automatic Route Selection. Default and Special
Numbers Tables
No time is specified, thus all calls are routed according
to Subpattern A
0000-2359
No
No
Tables ARS Sub B Start
Enter Drop Dial start time
stop Dial table no.
time Enter Exit
[F8] [F6] [F8]
[Alt] [P]
+ Type start time
[F10]
Type table no.
[F10] [F5]
time
Start and Stop Times for Subpatterns
[F5]
Dial table no.
Enter Sub B
Enter Drop Dial stop
Exit
[F10]
Type table no.
[F10] [F9]
[Alt] [P]
+ Type stop
[F5]
