Programming Procedures
Test Telephone Number
Use this procedure to assign a test line or trunk telephone number for each
100D module installed in the control unit.
The number assigned to the test line/trunk must be different from the numbers
assigned to other channels in the same B-channel group. It must be the same
as the number provided by the PRI service provider.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press on the PC before saving your entry or menu selection.
Summary: Test Telephone Number
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
3-198 Test Telephone Number
Sys Program
Exit
[F1]
press any key
System manager
All
Not required
Form 3b, Incoming Trunks - DS1 Connectivity (100D
Module)
Not applicable
Telephone number
No
No
LinesTrunks PRI
Enter Drop Dial telephone no.
Exit E x i t
[F4] [F6] [F4]
[Alt] [P]
+ Type telephone no.
[F5]
Test TelNum Dial sIot no.
Enter
[F10]
Type slot no.
[F10] [F5] [F5]
