Programming with SPM
Integrated Solution II System Manager's Guide, Order No. 555-600-726
Integrated Solution II Installation and Maintenance Guide, Order No.
555-600-720

Introduction to SPM

Figure 2-1 illustrates the SPM display.

Figure 2-1. The SPM Display

SPM screens simulate the system programming console. Each SPM screen
includes a 7-line by 24-character console simulation window that corresponds
to the display area of the MLX-20L telephone. To the right and left of this
console simulation window are columns, listing the keys that correspond to
similarly located buttons on the MLX-20L telephone. If you are working with
Version 2.00 or higher (2.xx),
screen, as shown in Figure 2-1.
The 10 function keys, identified on the screen as
to select screen options. When a screen offers you several choices, press the
function key identified by the label next to your choice. (If you were
programming on the console, you would press the telephone button next to your
choice. )
Introduction to SPM
2-2
2 appears in the upper left-hand corner of the
V
[ F1 ] [ F10 ],
through are used
