Programming Procedures
S i g n a l i n g
Use this procedure to specify whether the type of dialing signal from the local
telephone company is touch-tone or rotary.
NOTE:
DID trunks apply only in Hybrid/PBX mode.
Entering Programming
Console: Select Menu
PC/SPM: Type SPM
Exiting Without Changes
To exit from any screen without making changes, select Exit on the console or
[F5]
press on the PC before saving your entry or menu selection. Touch-tone
dial mode cannot be programmed for immediate start DID trunks.
Touch-tone single-line telephone users cannot make calls by using individual
trunks programmed for rotary operation. The touch-tone signals generated from
the telephone while dialing are transmitted to the central office at the same time
the rotary signals are sent to the system. The central office receives both
signals and cannot process the call.
Summary: Signaling
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
3-168 Signaling
Sys Program
Exit
[F1]
press any key
System manager
Hybrid/PBX
Not required
Form 3d, Incoming Trunks - DID
Rotary
Rotary, Touch-tone
No
No
LinesTrunks DID
block 170. Enter
Exit Exit
[F4] [F4] [F8]
[F10] [F1] [F2]
/
[F5]
Signaling Dial trunk
Rotary/TouchTone
Type trunk block no.
[F10] [F5]
Enter
[ F 5 ]
