Programming Procedures
Display/Instructions
Step
To save your entry when all
entries are complete
For a block of lines, do the
following:
1. Select the DID trunks
associated with the 20
line buttons on the
system programming
console.
2. Check green LEDs for
feature status.
The green LED indicates the
Fo//owing:
on = assign
off = remove DID trunk
To return to System
Programming menu
Block Assignment
3-152
On the console
Select Enter.
Select Lines 01-20,
Lines 21-40,
Lines 41–60, or
Lines 61-80.
Toggle the LED On/Off,
as required.
trunk to
DID
block
from block
Select Exit three
times.
On the PC
[F10]
Press
[F1], [F2]
Press
[F3], [F4]
or
Toggle the letter G
On/Off, as required.
[F5]
Press three times.
