Programming Overview

Figure 1-6. Data Entry Screen

If any data is currently programmed for the feature, it displays on the screen.
Some screens also show data entered on a previous screen, such as an
extension or trunk number.
A data entry screen may also offer menu selections—instead of entering data
from the dialpad, you select options on the screen, such as Yes or No, to enable
or disable a feature. These options are selected by pressing the button next to
the option. Your selection is highlighted. To program or save that selection, you
press the button next to Enter
Verifying Data Entry
You can use the Inspect feature to verify or check the entries you save. For
example, Figure 1-7 shows a data entry screen with the first of two required
extension numbers needed to assign analog voice and data.

Figure 1-7. Inspect Example

After 7108 is entered and saved, the system automatically assigns the next
sequential station jack number. This station jack pair does not display on the
data entry screen; however, if you press Inspct, the pair displays as shown on
the Inspect screen in Figure 1-8.
Option Selected
Assign Lines/Trunks:
Prompt Enter extension
Data Entry Area
Backspace
Exit
[ F10 ]
on the PC.
Data Voice/Data
Enter voice/data pair
—
Extension Entered
Backspace
Exit
Enter
7108
Delete
Enter
Programming Procedures 1-11
