ST STM32L4+ Series Reference Manual page 1956

Serial audio interface (SAI)
Bits 31:0 DATA[31:0]: Data
A write to this register loads the FIFO provided the FIFO is not full.
A read from this register empties the FIFO if the FIFO is not empty.
53.6.17 SAI data register (SAI_BDR)
Address offset: 0x040
Reset value: 0x0000 0000
31 30 29
rw rw rw
15 14 13
rw rw rw
Bits 31:0 DATA[31:0]: Data
A write to this register loads the FIFO provided the FIFO is not full.
A read from this register empties the FIFO if the FIFO is not empty.
53.6.18 SAI PDM control register (SAI_PDMCR)
Address offset: 0x0044
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. Res. Res.
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:10 Reserved, must be kept at reset value.
Bit 9 CKEN2: Clock enable of bitstream clock number 2
This bit is set and cleared by software.
0: SAI_CK2 clock disabled
1: SAI_CK2 clock enabled
Note: It is not recommended to configure this bit when PDMEN = 1.
1956/2301
28 27 26 25
rw rw rw rw
12 11 10 9
rw rw rw rw
28 27 26 25
Res. Res. Res.
12 11 10 9
Res. Res. CKEN2 CKEN1
rw
24 23 22 21
DATA[31:16]
rw rw rw rw
8 7 6 5
DATA[15:0]
rw rw rw rw
24 23 22
Res. Res. Res. Res.
8 7 6
Res. Res. MICNBR[1:0]
rw
RM0432 Rev 6
20 19 18
rw rw rw
4 3 2
rw rw rw
21 20 19 18
Res. Res. Res.
5 4 3 2
Res. Res.
rw rw
RM0432
17 16
rw rw
1 0
rw rw
17 16
Res. Res.
1 0
Res. PDMEN
rw
