uniquely determined without accessing the TLB. If the virtual address belongs to the P0, U0, or P3
area, the TLB is searched using the virtual address, and if the virtual address is recorded in the
TLB, a TLB hit is made and the corresponding physical address is read from the TLB. If the
accessed virtual address is not recorded in the TLB, a TLB miss exception is generated and
processing switches to the TLB miss exception handling routine. In the TLB miss exception
handling routine, the address translation table in external memory is searched, and the
corresponding physical address and page management information are recorded in the TLB. After
the return from the exception handling routine, the instruction which caused the TLB miss
exception is re-executed.
3.3.6
Single Virtual Memory Mode and Multiple Virtual Memory Mode
There are two virtual memory systems, single virtual memory and multiple virtual memory, either
of which can be selected with the MMUCR.SV bit. In the single virtual memory system, a number
of processes run simultaneously, using virtual address space on an exclusive basis, and the
physical address corresponding to a particular virtual address is uniquely determined. In the
multiple virtual memory system, a number of processes run while sharing the virtual address
space, and a particular virtual address may be translated into different physical addresses
depending on the process. The only difference between the single virtual memory and multiple
virtual memory systems in terms of operation is in the TLB address comparison method (see
section 3.4.3, Address Translation Method).
3.3.7
Address Space Identifier (ASID)
In multiple virtual memory mode, the 8-bit address space identifier (ASID) is used to distinguish
between processes running simultaneously while sharing the virtual address space. Software can
set the ASID of the currently executing process in PTEH in the MMU. The TLB does not have to
be purged when processes are switched by means of ASID.
In single virtual memory mode, ASID is used to provide memory protection for processes running
simultaneously while using the virtual memory space on an exclusive basis.
Notes: (1) In single virtual memory mode of the SH7751 Series, entries with the same virtual
page number (VPN) but different ASIDs cannot be set in the TLB simultaneously.
(2) In single virtual memory mode of the SH7751, if the UTLB contains address
translation information including an ITLB miss address with a different ASID and
unshared state (SH bit is 0), SH7751 may hang up or an instruction TLB multiple hit
exception may occur during hardware ITLB miss handling (see section 3.5.4,
Hardware ITLB Miss Handling). To avoid this, when switching the ASID values
(PTEH and ASID) of the current processing, purge the UTLB, or manage the changes
of the program instruction addresses in user mode so that no instruction is executed in
an address area (including overrun prefetch of instruction) that is registered in the
Rev. 3.0, 04/02, page 64 of 1064
