RM0090
OTG_FS Host non-periodic transmit FIFO size register
(OTG_FS_HNPTXFSIZ)/Endpoint 0 Transmit FIFO size (OTG_FS_DIEPTXF0)
Address offset: 0x028
Reset value: 0x0000 0200
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
NPTXFD/TX0FD
Host mode
Bits 31:16 NPTXFD: Non-periodic TxFIFO depth
Bits 15:0 NPTXFSA: Non-periodic transmit RAM start address
Device mode
Bits 31:16 TX0FD: Endpoint 0 TxFIFO depth
Bits 15:0 TX0FSA: Endpoint 0 transmit RAM start address
OTG_FS non-periodic transmit FIFO/queue status register
(OTG_FS_HNPTXSTS)
Address offset: 0x02C
Reset value: 0x0008 0200
Note:
In Device mode, this register is not valid.
This read-only register contains the free space information for the non-periodic TxFIFO and
the non-periodic transmit request queue.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
NPTXQTOP
r
r/rw
This value is in terms of 32-bit words.
Minimum value is 16
Maximum value is 256
This field contains the memory start address for non-periodic transmit FIFO RAM.
This value is in terms of 32-bit words.
Minimum value is 16
Maximum value is 256
This field contains the memory start address for the endpoint 0 transmit FIFO RAM.
NPTQXSAV
r
DocID018909 Rev 11
USB on-the-go full-speed (OTG_FS)
9
8
7
6
5
NPTXFSA/TX0FSA
r/rw
9
8
7
6
5
NPTXFSAV
r
4
3
2
1
0
4
3
2
1
0
1279/1731
1368
