Flexible memory controller (FMC)
The one HCLK cycle at the end of the write transaction helps guarantee the address and
data hold time after the NWE rising edge. Due to the presence of this HCLK cycle, the
DATAST value must be greater than zero (DATAST > 0).
Bit
number
31-21
20
19
18:16
15
14
13
12
11
10
9
8
7
6
5-4
3-2
1
0
Bit
number
31:30
29-28
27-24
23-20
19-16
15-8
1606/1731
Table 264. FMC_BCRx bit fields
Bit name
Reserved
0x000
CCLKEN
As needed
CBURSTRW
0x0 (no effect in asynchronous mode)
CPSIZE
0x0 (no effect in asynchronous mode)
Set to 1 if the memory supports this feature. Otherwise keep at
ASYNCWAIT
0.
EXTMOD
0x0
WAITEN
0x0 (no effect in asynchronous mode)
WREN
As needed
WAITCFG
Don't care
WRAPMOD
0x0
WAITPOL
Meaningful only if bit 15 is 1
BURSTEN
0x0
Reserved
0x1
FACCEN
Don't care
MWID
As needed
MTYP[1:0]
As needed, exclude 0x2 (NOR Flash memory)
MUXE
0x0
MBKEN
0x1
Table 265. FMC_BTRx bit fields
Bit name
Reserved
0x0
ACCMOD
Don't care
DATLAT
Don't care
CLKDIV
Don't care
BUSTURN
Time between NEx high to NEx low (BUSTURN HCLK)
Duration of the second access phase (DATAST+1 HCLK cycles for
DATAST
write accesses, DATAST HCLK cycles for read accesses).
