Rtc Alarm B Sub Second Register (Rtc_Alrmbssr) - STMicroelectronics STM32F405 Reference Manual

RM0090
Note: This register can be written only when ALRAE is reset in RTC_CR register, or in initialization
mode.
This register is write protected. The write access procedure is described in
write protection on page 794
26.6.19

RTC alarm B sub second register (RTC_ALRMBSSR)

Address offset: 0x48
Backup domain reset value: 0x0000 0000
System reset: not affected
31 30 29
Reserved
r r r
15 14 13
Reserved
r rw rw
Bits 31:28 Reserved
Bits 27:24 MASKSS[3:0]: Mask the most-significant bits starting at this bit
Bits 23:15 Reserved
Bits 14:0 SS[14:0]: Sub seconds value
Note: This register can be written only when ALRBIE is reset in RTC_CR register, or in
initialization mode.
This register is write protected.The write access procedure is described in
register write protection
28 27 26 25
MASKSS[3:0]
r rw rw rw
12 11 10 9
rw rw rw rw
0x0: No comparison on sub seconds for Alarm B. The alarm is set when the seconds unit is
incremented (assuming that the rest of the fields match).
0x1: SS[14:1] are don't care in Alarm B comparison. Only SS[0] is compared.
0x2: SS[14:2] are don't care in Alarm B comparison. Only SS[1:0] are compared.
0x3: SS[14:3] are don't care in Alarm B comparison. Only SS[2:0] are compared.
...
0xC: SS[14:12] are don't care in Alarm B comparison. SS[11:0] are compared.
0xD: SS[14:13] are don't care in Alarm B comparison. SS[12:0] are compared.
0xE: SS[14] is don't care in Alarm B comparison. SS[13:0] are compared.
0xF: All 15 SS bits are compared and must match to activate alarm.
The overflow bits of the synchronous counter (bits 15) is never compared. This bit can be
different from 0 only after a shift operation.
This value is compared with the contents of the synchronous prescaler's counter to
determine if Alarm B is to be activated. Only bits 0 up to MASKSS-1 are compared.
