STMicroelectronics STM32F405 Reference Manual page 1196

Ethernet (ETH): media access control (MAC) with DMA controller
Ethernet MAC interrupt status register (ETH_MACSR)
Address offset: 0x0038
Reset value: 0x0000 0000
The ETH_MACSR register contents identify the events in the MAC that can generate an
interrupt.
15 14 13
Reserved
Bits 15:10 Reserved, must be kept at reset value.
Bit 9 TSTS: Time stamp trigger status
Bits 8:7 Reserved, must be kept at reset value.
Bit 6 MMCTS: MMC transmit status
Bit 5 MMCRS: MMC receive status
Bit 4 MMCS: MMC status
Bit 3 PMTS: PMT status
Bits 2:0 Reserved, must be kept at reset value.
1196/1731
12 11 10 9
TSTS
rc_r
This bit is set high when the system time value equals or exceeds the value specified in the
Target time high and low registers. This bit is cleared by reading the ETH_PTPTSSR
register.
This bit is set high whenever an interrupt is generated in the ETH_MMCTIR Register. This bit
is cleared when all the bits in this interrupt register (ETH_MMCTIR) are cleared.
This bit is set high whenever an interrupt is generated in the ETH_MMCRIR register. This bit
is cleared when all the bits in this interrupt register (ETH_MMCRIR) are cleared.
This bit is set high whenever any of bits 6:5 is set high. It is cleared only when both bits are
low.
This bit is set whenever a Magic packet or Wake-on-LAN frame is received in Power-down
mode (See bits 5 and 6 in the ETH_MACPMTCSR register
status register (ETH_MACPMTCSR) on page
of this last register, are cleared due to a read operation to the ETH_MACPMTCSR register.
DocID018909 Rev 11
8 7 6 5
MMCTS MMCRS MMCS
Reserved
r r
1193). This bit is cleared when both bits[6:5],
RM0090
4 3 2 1
PMTS
Reserved
r r
Ethernet MAC PMT control and
0
