RM0090
MII_RX_CLK
MII_RX_DV
MII_RXD[3:0]
MII_RX_ERR
MII_RX_CLK
MII_RX_DV
MII_RXD[3:0]
MII_RX_ERR
MII_RX_CLK
MII_RX_DV
MII_RXD[3:0]
MII_RX_ERR
33.5.4

MAC interrupts

Interrupts can be generated from the MAC core as a result of various events.
The ETH_MACSR register describes the events that can cause an interrupt from the MAC
core. You can prevent each event from asserting the interrupt by setting the corresponding
mask bits in the Interrupt Mask register.
Ethernet (ETH): media access control (MAC) with DMA controller

Figure 367. Reception with no error

PREAMBLE

Figure 368. Reception with errors

PREAMBLE SFD

Figure 369. Reception with false carrier indication

XX XX XX XX
DocID018909 Rev 11
SFD
DA DA XX
0E XX XX
FCS
ai15634
XX XX
XX XX
1141/1731
ai15635
ai15636
