RM0090
Input SAI_CK_x clock
frequency
192 kHz x 256
44.1 kHz x 256
SAI_CK_x = MCLK
1. This may happen when the product clock controller selects an external clock source, instead of PLL clock.
The master clock may be generated externally on an I/O pad for external decoders if the
corresponding audio block is declared as master with bit NODIV = 0 in the SAI_xCR1
register. In slave, the value set in this last bit is ignored since the clock generator is OFF,
and the MCLK_x I/O pin is released for use as a general purpose I/O.
The bit clock is derived from the master clock. The bit clock divider sets the divider factor
between the bit clock SCK_x and the master clock MCLK_x following the formula:
SCK_x = MCLK x (FRL[7:0] +1) / 256
where:
256 is the fixed ratio between MCLK and the audio frequency sampling.
FRL[7:0] is the number of bit clock - 1 in the audio frame, configured in the SAI_xFRCR
register.
It is mandatory in master mode that (FRL[7:0] +1) should be equal to a number with a power
of 2 (refer to
clock. The 50% duty cycle is guaranteed on the bit clock SCK_x.
The SAI_CK_x clock can be also equal to the bit clock frequency. In this case, bit NODIV in
the SAI_xCR1 register should be set and the value inside the MCKDIV divider and the bit
clock divider will be ignored. In this case, the number of bits per frame is fully configurable
without the need to be equal to a power of two.
The bit clock strobing edge on SCK can be configured by bit CKSTR in the SAI_xCR1
register.
29.10

Internal FIFOs

Each audio block in the SAI has its own FIFO. Depending if the block is defined to be a
transmitter or a receiver, the FIFO will be written or read, respectively. There is therefore
only one FIFO request linked to FREQ bit in the SAI_xSR register.

Table 129. Example of possible audio frequency sampling range

Most usual audio frequency
sampling achievable
(1)
Section 29.7) in order to have an even integer number of MCLK_x pulses by bit
DocID018909 Rev 11
192 kHz
96 kHz
48 kHz
16 kHz
8 kHz
44.1 kHz
22.05 kHz
11.025 kHz
MCLK
Serial audio interface (SAI)
MCKDIV[3:0]
MCKDIV[3:0] = 0000
MCKDIV[3:0] = 0001
MCKDIV[3:0] = 0010
MCKDIV[3:0] = 0100
MCKDIV[3:0] = 1000
MCKDIV[3:0] = 0000
MCKDIV[3:0] = 0001
MCKDIV[3:0] = 0010
MCKDIV[3:0] = 0000
