Universal synchronous asynchronous receiver transmitter (USART)
30.6.8 USART register map
The table below gives the USART register map and reset values.
Offset Register
USART_SR
0x00
Reset value
USART_DR
0x04
Reset value
USART_BRR
0x08
Reset value
USART_CR1
0x0C
Reset value
USART_CR2
0x10
Reset value
USART_CR3
0x14
Reset value
USART_GTPR
0x18
Reset value
Refer to Section: Memory map for the register boundary addresses.
