Debug support (DBG)
Address
0xE0041010 ETM Status
0xE0041008 ETM Trigger Event
0xE004101C
0xE0041020 ETM Trace Enable Event
0xE0041024 ETM Trace Start/Stop
38.15.4

Configuration example

To output a simple value to the TPIU:
•
Configure the TPIU and enable the I/IO_TRACEN to assign TRACE I/Os in the
STM32F4xx debug configuration register.
•
Write 0xC5ACCE55 to the ETM Lock Access Register to unlock the write access to the
ITM registers
•
Write 0x00001D1E to the control register (configure the trace)
• Write 0000406F to the Trigger Event register (define the trigger event)
•
Write 0000006F to the Trace Enable Event register (define an event to start/stop)
• Write 00000001 to the Trace Start/stop register (enable the trace)
•
Write 0000191E to the ETM Control Register (end of configuration)
38.16 MCU debug component (DBGMCU)
The MCU debug component helps the debugger provide support for:
•
Low-power modes
•
Clock control for timers, watchdog, I2C and bxCAN during a breakpoint
•
Control of the trace pins assignment
38.16.1 Debug support for low-power modes
To enter low-power mode, the instruction WFI or WFE must be executed.
The MCU implements several low-power modes which can either deactivate the CPU clock
or reduce the power of the CPU.
The core does not allow FCLK or HCLK to be turned off during a debug session. As these
are required for the debugger connection, during a debug, they must remain active. The
MCU integrates special means to allow the user to debug software in low-power modes.
