Intel 6 SERIES CHIPSET - DATASHEET 01-2011 Datasheet page 804

Bit
13:9
8
7
6
5
4
804
Timer n Interrupt Rout (Tn_INT_ROUT_CNF) — R/W / RO. This 5-bit field
indicates the routing for the interrupt to the 8259 or I/O (x) APIC. Software writes to
this field to select which interrupt in the 8259 or I/O (x) will be used for this timer's
interrupt. If the value is not supported by this particular timer, then the value read
back will not match what is written. The software must only write valid values.
Timer 4, 5, 6, 7: This field is Read Only and reads will return 0.
NOTES:
1. If the interrupt is handled using the 8259, only interrupts 0–15 are applicable
and valid. Software must not program any value other than 0–15 in this field.
2. If the Legacy Replacement Rout bit is set, then Timers 0 and 1 will have a
different routing, and this bit field has no effect for those two timers.
3. Timer 0,1: Software is responsible to make sure it programs a valid value (20,
21, 22, or 23) for this field. The PCH logic does not check the validity of the
value written.
4. Timer 2: Software is responsible to make sure it programs a valid value (11,
20, 21, 22, or 23) for this field. The PCH logic does not check the validity of the
value written.
5. Timer 3: Software is responsible to make sure it programs a valid value (12,
20, 21, 22, or 23) for this field. The PCH logic does not check the validity of the
value written.
6. Timers 4, 5, 6, 7: This field is always Read Only 0 as interrupts from these
timers can only be delivered using direct processor interrupt messages.
Timer n 32-bit Mode (TIMERn_32MODE_CNF) — R/W or RO. Software can set
this bit to force a 64-bit timer to behave as a 32-bit timer.
Timer 0:Bit is read/write (default to 0). 0 = 64 bit; 1 = 32 bit
Timers 1, 2, 3, 4, 5, 6, 7:Hardwired to 0. Writes have no effect (since these seven
NOTE: When this bit is set to 1, the hardware counter will do a 32-bit operation on
comparator match and rollovers; thus, the upper 32-bit of the Timer 0
Comparator Value register is ignored. The upper 32-bit of the main counter is
not involved in any rollover from lower 32-bit of the main counter and
becomes all zeros.
Reserved. This bit returns 0 when read.
Timer n Value Set (TIMERn_VAL_SET_CNF) — R/W. Software uses this bit only
for Timer 0 if it has been set to periodic mode. By writing this bit to a 1, the software
is then allowed to directly set the timer's accumulator. Software does not have to
write this bit back to 1 (it automatically clears).
Software should not write a 1 to this bit position if the timer is set to non-periodic
mode.
NOTE: This bit will return 0 when read. Writes will only have an effect for Timer 0 if it
is set to periodic mode. Writes will have no effect for Timers 1, 2, 3, 4, 5, 6,
7.
Timer n Size (TIMERn_SIZE_CAP) — RO. This read only field indicates the size of
the timer.
Timer 0:Value is 1 (64-bits).
Timers 1, 2, 3, 4, 5, 6, 7: Value is 0 (32-bits).
Periodic Interrupt Capable (TIMERn_PER_INT_CAP) — RO. If this bit is 1, the
hardware supports a periodic mode for this timer's interrupt.
Timer 0: Hardwired to 1 (supports the periodic interrupt).
Timers 1, 2, 3, 4, 5, 6, 7: Hardwired to 0 (does not support periodic interrupt).
High Precision Event Timer Registers
Description
timers are 32-bits).
