R&S ESR Series User Manual page 684

®
R&S ESR
Suffix:
<n>
Parameters:
<Peaks>
<Subranges>
Example:
Manual operation:
CALCulate<n>:PEAKsearch|PSEarch:SUBRanges:PCOunt <Peaks>
This command defines the number of peaks to be found in each subrange.
Before you can use this command, you have to select the subrange peak search mode
with CALCulate<n>:PEAKsearch|PSEarch:METHod.
Parameters:
<Peaks>
Example:
Manual operation:
11.4.6.4 Peak Lists
Commands useful to read peak lists described elsewhere:
●
FORMat:DEXPort:DSEParator
DISPlay[:WINDow<n>]:TRACe<t>:SYMBol
MMEMory:STORe:FINal
MMEMory:STORe:PEAKlist
User Manual 1175.7068.02 ─ 12
.
irrelevant
If you have selected the "Peaks" search mode, the command
defines the number of peaks to look for during the peak search.
Range: 1 to 500
*RST: 50
If you have selected the Subranges search mode, the command
defines the number of subranges that the scan range is split
into.
Range: 1 to 50
*RST: 10
CALC:PEAK:METH SUBR
CALC:PEAK:SUBR 25
Selects a subrange search and defines 25 subranges.
See "No Of Peaks" on page 193
See "No of Subranges / Peaks per Subrange"
Number of peaks in one subrange.
Note that the maximum number of peaks is 500. Thus, the maxi-
mum number of peaks per subrange depends on the number of
subranges you have defined.
Range: 1 to depends on the number of subranges
*RST: 1
CALC:PSE:METH SUBR
CALC:PSE:SUBR 20
CALC:PSE:SUBR:PCO 5
Looks for 5 peaks in each of 20 subranges.
See "No of Subranges / Peaks per Subrange"
on page 850
.......................................................................682
................................................................................................. 682
............................................................................................ 682
Remote Control
Remote Commands in Receiver Mode
on page 193
on page 193
681
