  • Page 1: Quick Start Guide

    ® R&S EMI Test Receiver Quick Start Guide 1302.6163.62 – 04...
  • Page 2 Printed in Germany – Subject to change – Data without tolerance limits is not binding. ® R&S is a registered trademark of Rohde & Schwarz GmbH & Co. KG. Trade names are trademarks of the owners. The following abbreviations are used throughout this manual: ® R&S ESU is abbreviated as R&S ESU.

  • Page 3: Basic Safety Instructions

    Basic Safety Instructions Always read through and comply with the following safety instructions! All plants and locations of the Rohde & Schwarz group of companies make every effort to keep the safety standards of our products up to date and to offer our customers the highest possible degree of safety. Our products and the auxiliary equipment they require are designed, built and tested in accordance with the safety standards that apply in each case.
  • Page 4 Basic Safety Instructions Tags and their meaning The following signal words are used in the product documentation in order to warn the reader about risks and dangers. indicates a hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 5 Basic Safety Instructions Electrical safety If the information on electrical safety is not observed either at all to the extent necessary, electric shock, fire and/or serious personal injury or death may occur. 1. Prior to switching on the product, always ensure that the nominal voltage setting on the product matches the nominal voltage of the AC supply network.
  • Page 6 Basic Safety Instructions 14. Use suitable overvoltage protection to ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the product. Otherwise, the person operating the product will be exposed to the danger of an electric shock. 15.
  • Page 7 Basic Safety Instructions Repair and service 1. The product may be opened only by authorized, specially trained personnel. Before any work is performed on the product or before the product is opened, it must be disconnected from the AC supply network.
  • Page 8 Informaciones elementales de seguridad 2. Handles on the products are designed exclusively to enable personnel to transport the product. It is therefore not permissible to use handles to fasten the product to or on transport equipment such as cranes, fork lifts, wagons, etc. The user is responsible for securely fastening the products to or on the means of transport or lifting.
  • Page 9 Informaciones elementales de seguridad Se parte del uso correcto del producto para los fines definidos si el producto es utilizado conforme a las indicaciones de la correspondiente documentación del producto y dentro del margen de rendimiento definido (ver hoja de datos, documentación, informaciones de seguridad que siguen). El uso del producto hace necesarios conocimientos técnicos y ciertos conocimientos del idioma inglés.
  • Page 10 Informaciones elementales de seguridad Palabras de señal y su significado En la documentación del producto se utilizan las siguientes palabras de señal con el fin de advertir contra riesgos y peligros. PELIGRO identifica un peligro inminente con riesgo elevado que provocará...
  • Page 11 Informaciones elementales de seguridad Seguridad eléctrica Si no se siguen (o se siguen de modo insuficiente) las indicaciones del fabricante en cuanto a seguridad eléctrica, pueden producirse choques eléctricos, incendios y/o lesiones graves con posible consecuencia de muerte. 1. Antes de la puesta en marcha del producto se deberá comprobar siempre que la tensión preseleccionada en el producto coincida con la de la red de alimentación eléctrica.
  • Page 12 Informaciones elementales de seguridad 12. Si un producto se instala en un lugar fijo, se deberá primero conectar el conductor de protección fijo con el conductor de protección del producto antes de hacer cualquier otra conexión. La instalación y la conexión deberán ser efectuadas por un electricista especializado. 13.
  • Page 13 Informaciones elementales de seguridad 5. Ciertos productos, como p. ej. las instalaciones de radiocomunicación RF, pueden a causa de su función natural, emitir una radiación electromagnética aumentada. Deben tomarse todas las medidas necesarias para la protección de las mujeres embarazadas. También las personas con marcapasos pueden correr peligro a causa de la radiación electromagnética.
  • Page 14 Informaciones elementales de seguridad 6. En caso de falta de estanqueidad de una celda, el líquido vertido no debe entrar en contacto con la piel ni los ojos. Si se produce contacto, lavar con agua abundante la zona afectada y avisar a un médico.
  • Page 15 Sicherheitshinweise Kundeninformation zur Batterieverordnung (BattV) Dieses Gerät enthält eine schadstoffhaltige Batterie. Diese darf nicht mit dem Hausmüll entsorgt werden. Nach Ende der Lebensdauer darf die Entsorgung nur über eine Rohde&Schwarz-Kundendienststelle oder eine geeig- nete Sammelstelle erfolgen. Safety Regulations for Batteries (according to BattV) This equipment houses a battery containing harmful sub- stances that must not be disposed of as normal household...
  • Page 16 Customer Information Regarding Product Disposal The German Electrical and Electronic Equipment (ElektroG) Act is an implementation of the following EC directives: • 2002/96/EC on waste electrical and electronic equipment (WEEE) and • 2002/95/EC on the restriction of the use of certain hazardous substances in e lectrical and electronic equipment (RoHS).
  • Page 17 Qualitätszertifikat Certified Quality System ISO 9001 Certificate of quality Certified Environmental System Certificat de qualité ISO 14001 Sehr geehrter Kunde, Dear Customer, Cher client, Sie haben sich für den Kauf eines You have decided to buy a Vous avez choisi d’acheter un pro- Rohde &...
  • Page 18 EC Certificate of Conformity Certificate No.: 2009-69 This is to certify that: Equipment type Stock No. Designation 1302.6005.xx EMI Test Receiver complies with the provisions of the Directive of the Council of the European Union on the approximation of the laws of the Member States - relating to electrical equipment for use within defined voltage limits (2006/95/EC) - relating to electromagnetic compatibility...

  • Page 19: Customer Support

    Customer Support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer Support Centers. A team of highly qualified engineers provides telephone support and will work with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde &...
  • Page 20 Address List Headquarters, Plants and Subsidiaries Locations Worldwide Headquarters Please refer to our homepage: www.rohde-schwarz.com ◆ Sales Locations ROHDE&SCHWARZ GmbH & Co. KG Phone +49 (89) 41 29-0 Mühldorfstraße 15 · D-81671 München Fax +49 (89) 41 29-121 64 ◆ Service Locations P.O.Box 80 14 69 ·...

  • Page 21: Table Of Contents

    2.1.5 Switching On the R&S ESU ........2.6...
  • Page 22 R&S ESU Contents 2.4 Setup ............2.19 2.4.1 Selecting the Frequency Reference .
  • Page 23 R&S ESU Contents 4.2.4 Editing Alphanumeric Parameters ......4.9 4.2.4.1 Alphanumeric Editor Type 1: ......4.9 4.2.4.2 Alphanumeric Editor Type 2: .
  • Page 24 7.2 Detailed Programming Examples ....... . 7.9 7.2.1 Default Settings of the R&S ESU ......7.9 7.2.1.1 Setting the IEC Bus Status Registers .
  • Page 25 Appendix B: External Generator Control ....... . B.1 B.1 List of Generator Types Supported by the R&S ESU ....B.1 1 Index Quick Start Guide 1302.6163.62 - 04...
  • Page 26 R&S ESU Contents Quick Start Guide 1302.6163.62 - 04...
  • Page 27 FSU-B9 1142.8994.02 Tracking Generator FSP-B10 1129.7246.03 External Generator Control FSU-B12 1142.9349.02 Output Attenuator ESU-B18 1303.0400.06 Hard Disk ESU-B19 1303.0600.06 2nd Hard Disk ESU-B24 1157.2100.08/.26/.40 Preamplifier complies with the provisions of the Directive of the Council of the European Union on the...
  • Page 29 • Release Notes Apart from the base unit, these manuals describe the models and options of the R&S ESU EMI Test Receiver that are listed in the documentation overview of the Operating Manual. All other options are described in separate manuals. These manuals are provided on the CD-ROM. For an overview of all options available for the R&S ESU visit the R&S ESU EMI Test Receiver...
  • Page 30 Manual Operation see Quick Start Guide chapter 4 Chapter 4 Instrument Functions forms a reference for manual operation of the R&S ESU and contains a detailed description of all instrument functions and their application. Chapter 5 Remote Control - Basics describes the basics for programming the R&S ESU, command processing...
  • Page 31 R&S ESU Internet Site The Internet site at: R&S ESU EMI Test Receiver provides the most up to date information on the R&S FSUP. The current operating manual at a time is available as printable PDF file in the download area. Also provided for download are firmware updates including the associated release notes, instrument drivers, current data sheets and application notes.
  • Page 32 R&S ESU Quick Start Guide 1302.6163.62 - 04...

  • Page 33: Front And Rear Panel

    R&S ESU Front and Rear Panel 1 Front and Rear Panel 1.1 Front View ........... 1.2 1.2 Function Keys on the Front Panel .

  • Page 34: Front View

    R&S ESU Front and Rear Panel Front View 1.1Front View Front view Fig. 1-1 Number Description Fig. 1-1 PRESET key (see “ Function Keys on the Front Panel”) Calibration key (see “ Function Keys on the Front Panel”) SETUP key (see “...
  • Page 35 Number Description Fig. 1-1 rotary knob with enter function and arrow keys noise source supply voltage (see page CF card, option R&S ESU-B18 (see page USB interfaces (see page RF input 1/2 (see page probe power connector - supply voltage for measurement accessories (see...

  • Page 36: Function Keys On The Front Panel

    R&S ESU Front and Rear Panel Function Keys on the Front Panel 1.2 Function Keys on the Front Panel A detailed description of the corresponding menus and the other function keys is provided in the Operating Manual on CD-ROM. Function key...
  • Page 37 R&S ESU Front and Rear Panel Function Keys on the Front Panel Function key Assigned functions MEAS Selects the measurement function (receiver mode): • Detector and the measurement time selection • AF demodulator (receiver mode) • Data reduction and peak list •...

  • Page 38: Front Panel Connections

    R&S ESU Front and Rear Panel Front Panel Connections 1.3 Front Panel Connections This section describes the front connectors and interfaces of the R&S ESU. Optional connectors and interfaces are indicated by the option name in brackets. Ω RF INPUT 50 The RF input 1 (20 Hz ...
  • Page 39 Check the volume setting carefully before putting on the headphones in order to protect your hearing. PROBE POWER To allow you to connect transducers, the R&S ESU provides two PROBE POWER supply connectors. The left-hand connector supplies the ±10 V supply voltages and ground, making it suitable for attaching R&S transducers.
  • Page 40 R&S ESU Front and Rear Panel Front Panel Connections USB Interfaces The R&S ESU provides a USB female connector at the front panel for connecting two USB devices (USB 2.0). For pin assignment see page Use suitable double shielded cables.
  • Page 41 R&S ESU Front and Rear Panel Front Panel Connections Noise Source Control (NOISE SOURCE) The NOISE SOURCE female connector is used to switch an external noise source on and off in order, for example, to measure the noise figure of DUTs.

  • Page 42: Rear View

    R&S ESU Front and Rear Panel Rear View 1.4 Rear View Fig. 1-5 Rear view Number in Description Fig. 1-5 second GPIB interface for external generator control, option R&S FSP-B10 (see page LAN interface (see page IF output 20.4 MHz (see page I/Q input for tracking generator, option R&S FSU-B9 (see...
  • Page 43 R&S ESU Front and Rear Panel Rear View Number in Description Fig. 1-5 trigger/gate interface (see page double USB interface (see page mouse interface (see page VGA interface for external monitor (see page RS232-C interface (see page LPT printer interface (see...

  • Page 44: Rear Panel Connections

    For further information refer to the Operating Manual, chapter 8. Printer Interface (LPT) The 25-pin female LPT connector on the rear panel of the R&S ESU is provided for connecting a printer. The interface is compatible with the CENTRONICS interface. For further information refer to the Operating Manual, chapter 8.
  • Page 45 R&S ESU Front and Rear Panel Rear Panel Connections R&S Monitor Connection (MONITOR) The 15-pin VGA monitor connection is used to display the screen contents on an external screen. The procedure for putting the external monitor into operation is described in the section “...

  • Page 46: Usb Interface

    The voltage levels are adjustable (0.5 V to 3.5 V). The typical input impedance is 10 kΩ. USB Interface The R&S ESU provides a USB female connector at the rear panel for connecting two USB devices (upper connector USB 1.1, lower connector USB 2.0).
  • Page 47 R&S ESU Front and Rear Panel Rear Panel Connections In addition, the internal +5 V and +12 V power supply voltages are provided. The maximum load current is 100 mA. +5 V +12 V The user ports are configured in the SETUP menu (SETUP key), GENERAL SETUP / USER PORT sub-menu.
  • Page 48 Rear Panel Connections 20.4 MHz IF Output (IF OUT 20.4 MHz) The 20.4 MHz IF signal of the R&S ESU is provided at the 20.4 MHz OUT female BNC connector. For resolution bandwidths between 100 kHz and 10 MHz, the bandwidth corresponds to the selected bandwidth.
  • Page 49 AUX CONTROL (Option R&S FSP-B10) If option R&S FSP-B10 (external generator control) is built in, the R&S ESU provides a female connector that allows measurement data acquisition to be synchronized with the output signal of a Rohde & Schwarz generator.
  • Page 50 R&S ESU Front and Rear Panel Rear Panel Connections Signal Description n.c. not connected BLANK Return signalling from the signal generator indicating that frequency setting is completed TRIGGER Trigger signal for switching to the next frequency 6...9 Ground Fig. 1-10 Pin assignment of the AUX CONTROL connector 1.18...

  • Page 51: Preparing For Use

    2.1.4 Connecting the Instrument to the AC Power Supply ..2.6 2.1.5 Switching On the R&S ESU ..... . . 2.6 2.1.6 Functional Test .
  • Page 52 2.3.6 Connecting External Generators ....2.15 2.3.6.1 Connecting the R&S ESU to the Generator ..2.16 2.3.6.2 Configuring the Generator on the R&S ESU ..2.16 2.3.6.3 Activating the Generator Configuration and Setting...
  • Page 53 R&S ESU Preparing for Use 2.6.1 Properties Specific to Windows XP ....2.35 2.6.1.1 Windows XP Service Packs ....2.36 2.6.1.2 Opening the Windows XP Start Menu .

  • Page 54: Preparing For Operation

    R&S ESU Preparing for Use Preparing for Operation 2.1 Preparing for Operation This section describes how to put the instrument into operation. Before putting the instrument into operation, make sure that the following requirements have been met: • The air vents are not blocked.

  • Page 55: Installation In A 19" Rack

    R&S ESU Preparing for Use Preparing for Operation Risk of damaging electronic components To avoid damage of electronic components, the operational site must be protected against electrostatic discharge (ESD). Wrist strap with cord Building ground Floor mat Ground connection Heel strap...

  • Page 56: Connecting The Instrument To The Ac Power Supply

    Preparing for Operation 2.1.4 Connecting the Instrument to the AC Power Supply The R&S ESU is equipped with a mechanism for detecting AC power voltage and automatically sets itself to use the available AC power voltage (range: AC voltage 100 V to 240 V;...

  • Page 57: Switching Off The R&S Esu

    2.1.7 Switching Off the R&S ESU Press the ON/STANDBY key on the front panel. The R&S ESU will store the current settings on the hard disk and then shut down the software. Once the operation has been completed, the power supply unit will be switched to STANDBY and the yellow LED will come on.

  • Page 58: Cleaning The Outside

    Never use cleaning agents such as solvents (thinners, acetone, etc.), acids, bases, or other substances. 2.2 Instrument Drive Usage The harddisk space is divided in 3 logical drives (2 with option R&S ESU-B18): The harddisk space is divided in 3 logical drives. Contains the operating system Windows XP, printer driver, network driver,…...

  • Page 59: Connecting External Devices

    • Italian Keyboards • Portuguese Keyboards • Spanish Keyboards These drivers are already installed on the R&S ESU, if it is shipped with firmware version 4.3x or later. A separate installer file is available on the R&S ESU internet site.
  • Page 60 R&S ESU Preparing for Use Connecting External Devices 5. Select Settings - Control Panel - Regional and Language Options - Languages. 6. Select Details 7. Select Add and choose one of the available languages. Confirm your selection with OK. 2.10...

  • Page 61: Connecting A Mouse

    9. Reboot the R&S ESU 2.3.2 Connecting a Mouse To simplify Windows XP operation, the R&S ESU allows you to connect a mouse to one of the USB interfaces on the front or rear panel or the PS/2 mouse connector on the rear panel.

  • Page 62: Connecting An External Monitor

    R&S ESU Preparing for Use Connecting External Devices 2.3.3 Connecting an External Monitor Do not connect a monitor unless the instrument is switched off (STANDBY). Otherwise, you run the risk of damaging the monitor. You can connect an external monitor at the MONITOR connector on the instrument's rear panel.

  • Page 63: Connecting A Printer

    2.3.5 Connecting USB Devices (e.g. a Power Meter) The USB interface on the front and the rear panel of the R&S ESU allows you to connect up to 4 USB devices directly to the R&S ESU. This number can be increased as necessary by inserting USB hubs.
  • Page 64 R&S ESU Preparing for Use Connecting External Devices When a USB device is subsequently disconnected from the R&S ESU, Windows XP immediately detects the change in hardware configuration and deactivates the corresponding driver. Example: Connect a memory stick to the R&S ESU: 1.

  • Page 65: Connecting External Generators

    RF INPUT GEN OUTPUT The generator is controlled via the – optional – second GPIB interface of the R&S ESU (= IEC2, supplied together with the option). With some Rohde & Schwarz generators, it is also controlled via the TTL synchronization interface that is contained in the AUX CONTROL interface of the R&S ESU.

  • Page 66: Connecting The R&S Esu To The Generator

    Connecting External Devices 2.3.6.1 Connecting the R&S ESU to the Generator To couple the frequency setting and level setting of the generator to the R&S ESU, set up the following connections: 1. Connect the GPIB interface of the generator to the IEC2 connector on the rear panel of the R&S ESU.

  • Page 67: Level

    IFC column and press the ENTER key. The list of available control interfaces will appear. If the TTL interfaces from the R&S ESU and generator are connected, select TTL by using the rotary knob and then activate it by pressing the rotary knob.

  • Page 68: Using An External Generator As A Tracking Generator

    Switch on the external generator. Press the SPECTRUM hotkey to change to the analyzer mode. Press the NETWORK hotkey on the R&S ESU. Press the EXT SOURCE softkey. Tracking generator operation using an external generator will be activated. The external generator will switch to remote control and can be used like an internal tracking generator.

  • Page 69: Setup

    Setup 2.4 Setup 2.4.1 Selecting the Frequency Reference You can switch the reference signal for frequency processing of the R&S ESU between the internal reference and an external reference signal at 10 MHz as follows: Press the SETUP key. The SETUP menu will open.

  • Page 70: Setting The Gpib Interface

    R&S ESU Preparing for Use Setup Entering the date The day, month and year can be entered independently of each other in the entry field: To select the month, use the units key to open a list containing the month names. You can then select the month from the list.

  • Page 71: Gpib Language

    R&S ESU Preparing for Use Setup 2.4.3.2 GPIB Language Press the GPIB LANGUAGE softkey. The list of available remote control languages will open. The following languages are available: • SCPI • HP mode: 8560E, 8561E, 8562E, 8563E, 8564E, 8565E 8566A, 8566B, 8568A, 8568A_DC, 8568B, 8568B_DC, 71100C, 71200C, 71209A...

  • Page 72: Id Response String

    0 dBm DC (R&S ESU) Note regarding the selection of 856x for the R&S ESU: • The # of trace points is not switched over until the state changes to REMOTE. In the case of switchover to manual operation (LOCAL key), the number of sweep points is always changed to 625.
  • Page 73 R&S ESU Preparing for Use Setup Press the CONFIG DISPLAY softkey. The submenu for configuring the screen will open. The DEFAULT COLORS 1 and 2 softkeys set the default setting for brightness, tint and color saturation of all screen objects. The color schemes are selected in such a manner that all screen elements will be optimally visible regardless whether viewed from above or below.

  • Page 74: Automatically Switching Off The Internal Screen

    IEC bus command: DISP:CMAP1 ... 26:PDEF <color> 2.4.5 Automatically Switching Off the Internal Screen The R&S ESU provides a feature for automatically switching off the screen after a user- defined period of time. The background lighting will be disabled if no entries are made from the front panel after the selected response time (key, softkey or hardkey and rotary knob).

  • Page 75: File And Path Selection Using The Front Panel Keys

    R&S ESU Preparing for Use Setup 2.4.6 File and Path Selection Using the Front Panel Keys As of firmware version 4.3x the base system firmware supports new dialog boxes to select a folder and/or a file, e.g. for trace export.
  • Page 76 • first, the R&S ESU checks for a connected memory stick • if a memory stick is not recognized, then the R&S ESU uses the internal hard disk. Note that the path and file name are reset to their default values after an instrument PRESET.

  • Page 77: Selecting And Configuring Printers

    R&S ESU Preparing for Use Setup 2.4.7 Selecting and Configuring Printers Press the HCOPY key. The HARDCOPY menu will open. Press the DEVICE SETUP softkey. The dialog box for selecting the file format and printer will open: You can select a connected printer (including a pre-configured network printer) by...

  • Page 78: Selecting Alternative Printer Configurations

    Close button. 2.4.7.1 Selecting Alternative Printer Configurations The R&S ESU can support two independent hardcopy settings. This allows you to quickly switch between output to a file and a printer. To make a selection, use the DEVICE 1 / 2 softkey, which simultaneously shows the associated setting when the Hardcopy Setup dialog box is open.

  • Page 79: Installing Plug&Play Printers

    R&S ESU Preparing for Use Setup IEC bus command: HCOP:CMAP:DEF1 The OPTIMIZED COLORS softkey selects an optimized color setting for the printout in order to improve color clarity on the printout. With this selection, trace 1 will be printed out in blue, trace 2 in black, trace 3 in green and the markers in turquoise.

  • Page 80: Installing Non-Plug&Play Printers

    R&S ESU Preparing for Use Configuring the LAN Interface 2.4.9 Installing Non-Plug&Play Printers The procedure for installing non-plug&play printers is described in appendix A, section “ Installing Non-Plug&Play Printers” on page A.6. 2.5 Configuring the LAN Interface The instrument can be connected to an Ethernet LAN (local area network) using the LAN interface connector on the rear panel.

  • Page 81: Configuring The Interface

    R&S ESU Preparing for Use Configuring the LAN Interface 2.5.2.2 Configuring the Interface To configure the interface, do the following: Press the SETUP key. The SETUP menu will open. Press the GENERAL SETUP softkey. The submenu with all general settings will open.
  • Page 82 R&S ESU Preparing for Use Configuring the LAN Interface Open the Windows XP Start menu by pressing the Windows key or CTRL+ESC. Click Settings - Network Connections - Local Area Connection. The Local Area Connection Status dialog box will open.
  • Page 83 R&S ESU Preparing for Use Configuring the LAN Interface Click the Properties button. The window with the available network protocols opens. Click the network protocol you want (TCP/IP in the example). Click the Properties button. The dialog box with the settings for the selected network protocol will open. By default, Obtain an IP address automatically is selected.
  • Page 84 R&S ESU Preparing for Use Configuring the LAN Interface Select IP address and enter the IP address. Select Subnet mask and enter the required mask. Click OK. Windows XP will check the entered settings for correctness and then store the configuration.

  • Page 85: Installing Additional Network Protocols And Services

    R&S ESU Preparing for Use Operating System Properties Click Yes. Windows XP will restart the system. 2.5.2.4 Installing Additional Network Protocols and Services The procedure for installing additional network protocols and services is provided in the chapter “ Installing Additional Network Protocols & Services” on page 6.3.

  • Page 86: Windows Xp Service Packs

    R&S ESU. Thus, flawless instrument function is ensured only if software and hardware approved or offered by Rohde & Schwarz are used. Using other software or hardware may cause the functions of the R&S ESU to perform improperly or fail.
  • Page 87 R&S ESU Preparing for Use Operating System Properties • R&S Power Viewer (virtual power meter for displaying results of the power sensors of the R&S NRP-Zxx series) • Windows XP Remote Desktop • FileShredder – For reliable deletion of files on the hard disk •...
  • Page 88 R&S ESU Preparing for Use Operating System Properties 2.38 Quick Start Guide 1302.6163.62 - 04...

  • Page 89: Firmware Update And Installation Of Firmware Options

    R&S ESU Firmware Update and Installation of Firmware Options 3 Firmware Update and Installation of Firmware Options 3.1 Firmware Update ........3.2 3.2 Activating Firmware Options .

  • Page 90: Firmware Update

    R&S ESU Firmware Update and Installation of Firmware Options Firmware Update 3.1 Firmware Update For the latest firmware version refer to the Rohde & Schwarz internet site and download the most up-to-date firmware. A detailed description about performing the firmware update in the intrument is given in the release note, provided on this CD.

  • Page 91: Activating Firmware Options

    R&S ESU Firmware Update and Installation of Firmware Options Activating Firmware Options 3.2 Activating Firmware Options Firmware options are enabled by entering license keys via the following operating sequence: Press the SETUP key. The SETUP menu will open. Press the GENERAL SETUP softkey.
  • Page 92 R&S ESU Firmware Update and Installation of Firmware Options Activating Firmware Options Quick Start Guide 1302.6163.62 - 04...

  • Page 93: Basic Operation

    R&S ESU Basic Operation 4 Basic Operation 4.1 Diagram Layout ........4.2 4.1.1 Displays in the Diagram Area .

  • Page 94: Diagram Layout

    4.1 Diagram Layout Hardware Marker/Delta Marker/Delta Logo settings marker marker title/date Status Dirty flag information Enhancement labels Trace information Level axis labelling Frequency axis labelling Fig. 4-1 Screen layout of the R&S ESU during analyzer operation Quick Start Guide 1302.6163.62 - 04...

  • Page 95: Displays In The Diagram Area

    R&S ESU Basic Operation Diagram Layout 4.1.1 Displays in the Diagram Area Hardware settings Display of the reference level. Offset Display of the reference level offset. Display of the RF attenuation that has been set. Display of the resolution bandwidth that has been set.
  • Page 96 R&S ESU Basic Operation Diagram Layout Status displays The status displays on the left side of the diagram indicate any irregularities (e.g. UNCAL). UNCAL Indicates that one of the following conditions is present: • Correction data has been switched off (CAL menu, CAL CORR OFF).
  • Page 97 R&S ESU Basic Operation Diagram Layout Trace information Trace # Trace number Detector Detector Trace Selected detector: auto / number manual • AP: AUTOPEAK detector 1 PK * • PK: MAX PEAK detector CLRWR • MI: MIN PEAK detector • SA: SAMPLE detector...
  • Page 98 75 Ω The input impedance of the instrument is set to 75 Ω. The instrument is configured for operation with an external reference. The RF PREAMPLIFIER is switched on (option R&S ESU-B24). The PRESELECTOR is switched on. Gauss Filter (3 dB)

  • Page 99: Setting Parameters

    R&S ESU Basic Operation Setting Parameters 4.2 Setting Parameters 4.2.1 The Keypad The keypad is used to enter numeric parameters. It contains the following keys: • Numeric keys 0...9 • Decimal point Inserts a decimal point "." at the cursor position.

  • Page 100: The Rotary Knob And Arrow Keys

    R&S ESU Basic Operation Setting Parameters With frequency entries, the ENTER key corresponds to the Hz key. With time data, it corresponds to the µs (kHz) key. 4.2.2 The Rotary Knob and Arrow Keys The rotary knob and arrow keys are located next to the keypad.

  • Page 101: Editing Alphanumeric Parameters

    R&S ESU Basic Operation Setting Parameters 4.2.4 Editing Alphanumeric Parameters If an external keyboard is not available, the character selection field is automatically opened for entering alphanumeric parameters. Two models of the alphanumeric editor are available. 4.2.4.1 Alphanumeric Editor Type 1:...

  • Page 102: Alphanumeric Editor Type 2

    R&S ESU Basic Operation Setting Parameters 4.2.4.2 Alphanumeric Editor Type 2: The entry area consists of two parts: • The editing line • The character selection field u or arrow keys switch between the editing line and the character selection field.
  • Page 103 R&S ESU Basic Operation Setting Parameters Completing the entry (alternative 1) Using the rotary knob, select the EXIT field and then press the rotary knob. The data entry field will close, and the new entry will be accepted by the instrument.
  • Page 104 R&S ESU Basic Operation Setting Parameters 4.12 Quick Start Guide 1302.6163.62 - 04...
  • Page 105 R&S ESU Basic Measurement Examples 5 Basic Measurement Examples 5.1 Introduction ........5.3 5.2 Performing a Level and Frequency Measurement .
  • Page 106 R&S ESU Basic Measurement Examples 5.7.1 Storing an Instrument Configuration (without Traces) . . 5.34 5.7.1.1 Storing Traces ......5.35 5.7.2 Loading an Instrument Configuration .

  • Page 107: Introduction

    This section describes a typical and simple measurement task for an EMI test receiver. Each operating step is explained with the aid of R&S ESU for rapid familiarization of the user without the need to know all the details of the operating functions.

  • Page 108: Performing A Level And Frequency Measurement

    The high speed of fully synthesized scans, the frequency and amplitude accuracy and the wide dynamic range of the R&S ESU EMI Test Receiver are of utmost importance and very useful for these measurements.
  • Page 109 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement Start the scan. 7. Analyze the level in frequency domain. – Analyze the level in frequency domain using the marker functions. – Analyze the level in frequency domain using the peak search functions.
  • Page 110 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement 3. Program a SCAN TABLE. Press the SWEEP key. Press the TDOMAIN SCAN softkey A dialog box is displayed where the whole display range can be defined and divided into scan subranges.
  • Page 111 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement Fig. 5-3 Modified SCAN TABLE for preparing a scan After editing the scan subrange, the frequency display has to be adapted to the new settings. The lowest start frequency of the range 1 scan and the highest stop frequency of the subsequently defined subranges are used for defining the start and stop frequencies of the graphics display.
  • Page 112 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement 4. Select the detectors. Up to three detectors can be connected in parallel to simultaneously display the amplitude at every frequency as a function of detector weighting. When a parallel detector is selected, the slowest detector (in the sense of a calibrated measurement) determines the speed or the total measurement time required for the scan.
  • Page 113 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement Press the STOP SCAN softkey. The measurement is aborted. Peak and average results (see Fig. 5-4) should be further analyzed with the aid of the built-in marker functions. Depending on the DUT, diverse trace forms are obtained. For this reason the diagram below should be regarded as an example.
  • Page 114 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement 7. Analyze the level in frequency domain using the marker functions. Alternatively, you can use the peak search functions (see step 8). Press the MRK key. The marker jumps to the largest signal peak shown on the display screen.
  • Page 115 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement Press the FULL SCREEN softkey. One window is displayed on the screen Fig. 5-5 Screen display with marker 9. Set the SPLIT SCREEN function. The SPLIT SCREEN function simplifies the analysis of measured data, particularly at critical frequencies.
  • Page 116 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement 10.Tune the receiver frequency and obtain final test results using the QUASIPEAK detector. The currently measured frequency can be rapidly changed e.g. with the TUNE TO MARKER softkey in the MKR−> menu. Other or additional detectors can be switched on at this receive frequency and an overview of levels of all active detectors is given.
  • Page 117 11.From overview to standard-conformal measurement Data reduction and automatic routines for final measurement The R&S ESU offers several data reduction methods for interactive or automatic final measurements. For details refer to the Operating Manual, chapter 4. Limit lines A final measurement to standard can be performed when active limit lines are displayed in the diagram during the described analysis and measurements are repeated at all critical frequencies using the standard measurement time and a corresponding detector.
  • Page 118 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement 12.Store the test results, tables or diagrams. In the example, test results are stored on a memory stick. Measured data are output in WMF format for use in other applications.
  • Page 119 R&S ESU Basic Measurement Examples Performing a Level and Frequency Measurement Fig. 5-7 Result display stored in a file in WMF format A detailed description of the file management for complete EMI Test Receiver setups, data records for traces (traces 1-3), limit lines and transducer is given in the Operating Manual, chapter 4, section "Operating Concept of File Managers".

  • Page 120: Measuring A Sinusoidal Signal

    In the following examples, a signal generator is used as a signal source. Test setup: Connect the RF output of the signal generator to the RF input of R&S ESU. Settings on the signal generator: Frequency:...

  • Page 121: Increasing The Frequency Resolution

    R&S ESU Basic Measurement Examples Measuring a Sinusoidal Signal 4. Reduce the frequency span (SPAN) to 1 MHz. Press the SPAN key. Using the numeric keypad in the input field, enter 1 and confirm the entry with the MHz key.

  • Page 122: Setting The Reference Level

    (=reference level) or immediately below it. If the reference level that is selected is less than the highest signal that occurs in the spectrum, the signal path in the R&S ESU will be overloaded.

  • Page 123: Measuring The Signal Frequency Using The Frequency Counter

    The frequency sweep is stopped at the marker, and the R&S ESU measures the frequency of the signal at the marker position. In the following example, the frequency of the generator at 128 MHz is shown by using the marker.
  • Page 124 R&S ESU Basic Measurement Examples Measuring a Sinusoidal Signal Fig. 5-8 Measurement of the frequency with the frequency counter Obtaining a correct result when measuring the frequency with the internal frequency counter requires that an RF sinusoidal signal or a spectral line be present.

  • Page 125: Measuring Harmonics Of Sinusoidal Signals

    Press the START softkey and enter 100 MHz. Press the STOP softkey and enter 400 MHz. The R&S ESU displays the fundamental and the first and second harmonics of the input signal. 3. For maximum sensitivity, set the RF attenuation to 0 dB.

  • Page 126: Reducing Noise

    Markers delta 2 [T1] and delta 3 [T1] show the offset of the first and second harmonics from the fundamental. 5.4.2 Reducing Noise The R&S ESU offers three means of effectively differentiating the harmonics of a signal from the noise: • Reducing the video bandwidth •...
  • Page 127 R&S ESU Basic Measurement Examples Measuring Harmonics of Sinusoidal Signals 1. Reducing the noise by reducing the video bandwidth. Press the BW key. Press the VIDEO BW MANUAL softkey. Using the rotary knob (turning it counterclockwise), reduce the video bandwidth to 10 kHz (for example), or enter 10 kHz.

  • Page 128: Measuring Harmonics With Frequency Sweeps

    The sweep time is, therefore, also increased considerably. In this case, the measurement of individual harmonics is carried out with the R&S ESU set to a small span. Only the frequency range around the harmonics will then be measured with a small resolution bandwidth.
  • Page 129 Press the FREQ key. Enter 128 MHz. Press the SPAN key and enter 100 kHz. The R&S ESU displays the reference signal with a span of 100 kHz and resolution bandwidth of 2 kHz. 4. Activate the marker. Press the MKR key.
  • Page 130 R&S ESU Basic Measurement Examples Measuring Harmonics with Frequency Sweeps 6. Make the step size for the center frequency equal to the signal frequency. Press the FREQ key. Press the CF STEPSIZE softkey and press the =MARKER softkey in the submenu.

  • Page 131: Measuring Signal Spectra With Multiple Signals

    R&S ESU Basic Measurement Examples Measuring Signal Spectra with Multiple Signals The other harmonics are measured with steps 6 and 7, the center frequency being incremented or decremented in steps of 128 MHz using the up or down arrow key.
  • Page 132 Operating steps on the R&S ESU: 1. Reset the instrument. Press the PRESET key. The R&S ESU is now in the default state. Press the SPECTRUM hotkey. 2. Set the center frequency to 100.015 MHz and the frequency span (SPAN) to 300 kHz.
  • Page 133 The level drop is located exactly in the center of the screen only if the generator frequencies exactly match the frequency display of the R&S ESU. To achieve exact matching, the frequencies of the generators and the R&S ESU must be synchronized.
  • Page 134 R&S ESU Basic Measurement Examples Measuring Signal Spectra with Multiple Signals 4. Set the resolution bandwidth to 100 kHz. Press the RES BW MANUAL softkey and enter 100 kHz. It is no longer possible to clearly distinguish the two generator signals.
  • Page 135 R&S ESU Basic Measurement Examples Measuring Signal Spectra with Multiple Signals 5. Set the resolution bandwidth to 1 kHz. Turn the rotary knob counterclockwise until the bandwidth indicates 1 kHz. The two generator signals are shown with high resolution. However, the sweep time becomes noticeably longer (600 ms), since it increases at a rate of 1/RBW .

  • Page 136: Measuring The Modulation Depth Of An Am-Modulated Carrier In The Frequency Domain

    Since the dynamic range of an analyzer is very large, extremely small modulation depths can also be measured precisely. For this purpose, the R&S ESU provides measurement routines that directly output the modulation depth numerically in %.
  • Page 137 Press the MEAS key. Press the MODULATION DEPTH softkey. The R&S ESU automatically sets a marker to the carrier signal in the center of the diagram and one delta marker each to the upper and lower AM sidebands. The R&S ESU calculates the AM modulation depth from the level differences of the delta markers to the main marker and outputs the numeric value in the marker information field.

  • Page 138: Storing And Loading Instrument Settings

    Storing and Loading Instrument Settings 5.7 Storing and Loading Instrument Settings The R&S ESU can store complete instrument settings together with instrument configurations and measurement data internally as a data record. The data is stored on the built-in hard disk or –...

  • Page 139: Storing Traces

    R&S ESU Basic Measurement Examples Storing and Loading Instrument Settings The name of a data record may contain letters and digits. If necessary, the desired directory can be placed in front of the name of the data record (the directory will then automatically be used for any further save and recall operations).

  • Page 140: Automatic Loading Of A Data Record During Booting

    5.7.2.1 Automatic Loading of a Data Record during Booting If the R&S ESU is switched on in the factory default state, it loads the instrument settings that it had when switched off (provided that it was switched off using the STANDBY switch on the front panel;...

  • Page 141: Printing Out The Measurement Results

    R&S ESU Basic Measurement Examples Printing Out the Measurement Results Select the data record to be loaded by using the rotary knob and mark it with ENTER. Close the dialog box by pressing ESC twice. • The selected data record will also be loaded by pressing the PRESET key.

  • Page 142: Additional Measurement Examples

    5.9 Additional Measurement Examples The measurement examples provided in this section are intended as an introduction to operating the R&S ESU. For enhanced applications, refer to the Operating Manual, chapter 2, which provides a series of additional examples. Measurement examples for the instrument's options are provided in the Operating Manuals for the individual options.

  • Page 143: Lan Interface

    6.6.9 Sharing Directories (only with Microsoft Networks) ..6.21 6.7 Manual Operation of the R&S ESU with XP Remote Desktop ..........6.24 6.7.1 Introduction .
  • Page 144 6.7.5 Interrupting and Restoring the Remote Desktop Connection with the R&S ESU ......6.34 6.7.6 Deactivating the R&S ESU from the Controller ..6.35 In some of the following step-by-step instructions, user names and passwords must be entered.

  • Page 145: Installing Additional Network Protocols & Services

    R&S ESU LAN Interface Installing Additional Network Protocols & Services 6.1 Installing Additional Network Protocols & Services Your network administrator knows which protocols are necessary. In the case of the RSIB protocol and VXI11 support, TCP/IP must always be installed. In the following example, the support for Novell Network will also be installed..
  • Page 146 R&S ESU LAN Interface Installing Additional Network Protocols & Services Click the Install button. The list of available network components will open. Select Client. Click the Add... button. The list of available network protocols will open. Quick Start Guide 1302.6163.62 - 04...
  • Page 147 R&S ESU LAN Interface Installing Additional Network Protocols & Services Select Client Service for NetWare. Click the OK button. The network driver for Novell Netware will be installed. • Your network administrator knows which clients, services and protocols must be installed for your network.

  • Page 148: Configuration Examples

    R&S ESU LAN Interface Configuration Examples 6.2 Configuration Examples Network Protocols Services Comments NOVELL Netware NWLink IPX/SPX Client service for The frame type used in the network must compatible NetWare be set under Protocols - Properties. transport IP Networks TCP/IP...
  • Page 149 R&S ESU LAN Interface Subsequent Changes to the Network Configuration You can change the other settings after you select the other tabs. Before doing so, however, be sure to check with your network administrator. Click the Change button. The dialog box for changing the computer name, domain and workgroup will open.

  • Page 150: Configuring The Windows Xp Firewall

    R&S ESU LAN Interface Configuring the Windows XP Firewall 6.4 Configuring the Windows XP Firewall The Windows XP Firewall blocks all network communication which is not initialized by the controller itself or which is defined as unwanted. It protects the controller from an attack of hostile users and programs.

  • Page 151: Operating The Instrument Without A Network

    R&S ESU LAN Interface Operating the Instrument without a Network 6.5 Operating the Instrument without a Network If you want to operate the instrument either temporarily or permanently without a network connection, no special measures are necessary in contrast to Windows NT. Windows XP automatically detects the interruption of the network connection and does not set up the connection when the instrument is switched on.
  • Page 152 R&S ESU LAN Interface Operating the Instrument in a Network Select Create a new account. The dialog box for entering a new computer name will open. Enter the name of the new user in the text field and confirm with Next ->. The Pick an account type dialog box for defining the user's rights will open.

  • Page 153: Changing The User Password

    R&S ESU LAN Interface Operating the Instrument in a Network Conclude the creation of the new user by clicking the Create Account button. The new user has now been created. 6.6.2 Changing the User Password After the new user has been created on the instrument, the password must be adapted to the network password.
  • Page 154 R&S ESU LAN Interface Operating the Instrument in a Network Click Create a password. The dialog box for entering a new password will open. Enter the new password in the upper text line and repeat it in the following line.

  • Page 155: Novell Network Only: Configure Novell Client

    R&S ESU LAN Interface Operating the Instrument in a Network 6.6.3 NOVELL Network only: Configure NOVELL Client Using the Windows key or the key combination CTRL+ESC, call the Windows XP Start menu. Click Settings and then Control Panel and CSNW.

  • Page 156: Logging On To The Network

    R&S ESU LAN Interface Operating the Instrument in a Network If desired, click the Run Login Script entry. You can obtain this information from your network administrator. Conclude the login configuration with OK. 6.6.4 Logging On to the Network Network login occurs at the same time you log on to the operating system. For this to be possible, the user name and the password must be identical under Windows XP and on the network.

  • Page 157: Using Network Drives

    R&S ESU LAN Interface Operating the Instrument in a Network 6.6.7 Using Network Drives Using the Windows key or the key combination CTRL+ESC, call the Windows XP Start menu. Click Programs, and then Accessories and Windows Explorer. Under Desktop, click My Network Places and Entire Network All available network drives will be displayed.
  • Page 158 R&S ESU LAN Interface Operating the Instrument in a Network Under Drive: click the drive. Using Browse, open the list of network paths available in the network. Mark the desired network path. Activate Reconnect at Logon: if you want the connection to be set up automatically each time the instrument is started.

  • Page 159: Installing A Network Printer

    R&S ESU LAN Interface Operating the Instrument in a Network 6.6.8 Installing a Network Printer A new printer is installed using the INSTALL PRINTER softkey in the HCOPY menu. Click the HCOPY key. The HCOPY menu will open. Click the NEXT key to go to the side menu.
  • Page 160 R&S ESU LAN Interface Operating the Instrument in a Network Select Next with the rotary knob and then press the rotary knob to confirm. The Local or Network Printer selection will appear. In this example, an HP Laserjet 5 printer is installed as a network printer.
  • Page 161 R&S ESU LAN Interface Operating the Instrument in a Network Mark a printer and confirm with OK. When you are prompted to confirm the installation of a suitable printer driver, click OK. The selection of printer drivers will appear. The left-hand pane will list the manufacturers and the right-hand pane the available printer drivers.
  • Page 162 R&S ESU LAN Interface Operating the Instrument in a Network If the printer you need does not appear in the list, the driver has not yet been installed on the instrument. In this case, click the Have Disk button. You will then be prompted e.g. to connect a memory stick containing the required driver.

  • Page 163: Sharing Directories (Only With Microsoft Networks)

    R&S ESU LAN Interface Operating the Instrument in a Network Configure the R&S ESU for printout with this printer using the DEVICE SETUP and DEVICE 1/2 softkeys in the hardcopy main menu (see section “ Selecting and Configuring Printers” on page 2.27).
  • Page 164 R&S ESU LAN Interface Operating the Instrument in a Network Click the desired folder with the right mouse button. Click Sharing and Security. The dialog for sharing the directory will open. 6.22 Quick Start Guide 1302.6163.62 - 04...
  • Page 165 R&S ESU LAN Interface Operating the Instrument in a Network Click Share this folder. You can change the following settings as necessary: Share name: Name under which the directory appears in Explorer Comment: Comments regarding the shared directory User Limit:...

  • Page 166: Manual Operation Of The R&S Esu With Xp Remote Desktop

    • Storage of measured data on the controller's hard disk The R&S ESU is connected via a LAN, in which case Windows XP also supports a connection via a modem. This section describes the configuration of the R&S ESU and Remote Desktop Client of the control PC.
  • Page 167 R&S ESU LAN Interface Manual Operation of the R&S ESU with XP Remote Desktop Click the Support tab. The current TCP/IP configuration will be displayed. If Assigned by DHCP appears in the Address Type field, go to step 2 (Create a fixed IP address...).
  • Page 168 R&S ESU LAN Interface Manual Operation of the R&S ESU with XP Remote Desktop Select Settings - Control Panel - System. Select the Remote tab. In the Remote Desktop panel, select the check box in front of Allow users to connect remotely to this computer.

  • Page 169: Configuring The Controller

    The user account under which configuration is carried out is automatically enabled for Remote Desktop. Confirm the setting with OK. The R&S ESU is now ready for connection setup with the Remote Desktop program of the controller. 6.7.3 Configuring the Controller Before Remote Desktop can be operated, the TCP/IP protocol must be created on the controller and Remote Desktop Client must be installed.
  • Page 170 R&S ESU LAN Interface Manual Operation of the R&S ESU with XP Remote Desktop Select the Options >> button. The table with the configuration data will appear. Select the Experience tab. These settings are used to select and optimize the connection speed.
  • Page 171 Click the check box in front of Disk drives if you will need to access drives of the controller from the R&S ESU (e.g. in order to store settings or to copy files from the controller to the R&S ESU): Windows XP will then map drives of the controller to the R&S ESU like network drives.

  • Page 172: Connection Setup With The R&S Esu

    Display the connection bar when in full screen mode: If this option is enabled, a bar showing the network address of the R&S ESU will appear at the top edge of the screen. You can use this bar to reduce, minimize or close the window.
  • Page 173 After a few moments, the screen of the R&S ESU will appear on the controller's screen with the prompt for you to log on. To enable remote control of the R&S ESU, do the following: Enter “instrument” as the user name and “123456” as the password.

  • Page 174: The R&S Esu

    In this case, do the following: Press ALT+F4. The R&S ESU firmware will be shut down, which may take a few seconds. Double-click R&S Analyzer Interface. The firmware will restart and then automatically open the Soft Front Panel, i.e. the user interface on which all front panel controls and the rotary knob are mapped to buttons.
  • Page 175 R&S ESU LAN Interface Manual Operation of the R&S ESU with XP Remote Desktop Quick Start Guide 1302.6163.62 - 04 6.33...
  • Page 176 6.7.5 Interrupting and Restoring the Remote Desktop Connection with the R&S ESU The connection to the R&S ESU can be interrupted at any time by closing the Remote Desktop window on the controller. To restore the connection with the R&S ESU, merely follow the instructions provided in the section“...

  • Page 177: Deactivating The R&S Esu From The Controller

    Manual Operation of the R&S ESU with XP Remote Desktop 6.7.6 Deactivating the R&S ESU from the Controller The R&S ESU can be deactivated via remote control. To do so, proceed as follows: 1. Click the R&S ESU soft front panel and close the application with ALT+F4.
  • Page 178 R&S ESU LAN Interface Manual Operation of the R&S ESU with XP Remote Desktop 6.36 Quick Start Guide 1302.6163.62 - 04...

  • Page 179: Brief Introduction To Remote Control

    7.2 Detailed Programming Examples ....7.9 7.2.1 Default Settings of the R&S ESU ....7.9 7.2.1.1 Setting the IEC Bus Status Registers .
  • Page 180 7.4.2 Network Printer ....... . A.12 7.5 List of Generator Types Supported by the R&S ESU ..B.1...

  • Page 181: Basic Steps In Programming Using The Visa Interface

    R&S ESU Brief Introduction to Remote Control Basic Steps in Programming using the VISA Interface The instrument can be remote controlled via the GPIB interface. For details on setting the GPIB interface see chapter 2, section “ Setting the GPIB Interface” on page 2.20.

  • Page 182: Initialization And Default State

    R&S ESU Brief Introduction to Remote Control Basic Steps in Programming using the VISA Interface Accessing the functions of the VISA32.DLL To enable users to create Visual Basic control applications, the file dynamic link library VISA32.DLL has to be added to the project using the References command in the Project menu.

  • Page 183: Initializing The Controller

    R&S ESU Brief Introduction to Remote Control Basic Steps in Programming using the VISA Interface 7.1.2.2 Initializing the Controller This procedure first establishes a connection to the VISA layer and then to the instrument specified by the analyzerString. REM ------------ Initializing the controller -------------------------------...

  • Page 184: Configuring The Power Save Function For The Display

    R&S ESU Brief Introduction to Remote Control Basic Steps in Programming using the VISA Interface END SUB REM************************************************************************ 7.1.2.5 Configuring the Power Save Function for the Display During remote operation, it is often unnecessary to display the measurement results on screen.

  • Page 185: Reading Out Instrument Settings

    R&S ESU Brief Introduction to Remote Control Basic Steps in Programming using the VISA Interface 7.1.4 Reading Out Instrument Settings The settings made above can now be read out. To do so, the abbreviated commands are used. REM --------- Reading out instrument settings -----------------------------...

  • Page 186: Command Synchronization

    R&S ESU Brief Introduction to Remote Control Basic Steps in Programming using the VISA Interface 7.1.6 Command Synchronization The synchronization methods used in the following example are described in the Operating Manual, chapter 5, section "Command Sequence and Command Synchronization".

  • Page 187: Reading Output Buffers

    END SUB REM *********************************************************************** 7.2 Detailed Programming Examples 7.2.1 Default Settings of the R&S ESU The following settings provide typical examples of how to change the default settings of the R&S ESU. Note that only some of the settings are necessary depending on the application example. In...

  • Page 188: Setting The Iec Bus Status Registers

    7.2.1.2 Default Settings for Measurements REM ************************************************************************ Public Sub SetupInstrument() Dim status As ViStatus Dim retCnt As Long REM ------ Default setting of the R&S ESU ---------------------------------- Call SetupStatusReg 'Configure status registers status = viWrite(analyzer, "*RST", 4, retCnt) 'Reset instrument status = viWrite(analyzer, "INST:SEL SAN", 12, retCnt)
  • Page 189 R&S ESU Brief Introduction to Remote Control Detailed Programming Examples status = viWrite(analyzer, "FREQ:SPAN 1 MHz", 15, retCnt) 'Span REM ------ Level setting -------------------------------------------------- status = viWrite(analyzer, "DISP:WIND:TRAC:Y:RLEV -20dBm", 28, retCnt) 'Reference level status = viWrite(analyzer, "INP:ATT 10dB", 12, retCnt)

  • Page 190: Using Markers And Delta Markers

    R&S ESU Brief Introduction to Remote Control Detailed Programming Examples 7.2.2 Using Markers and Delta Markers 7.2.2.1 Marker Search Functions, Restricting the Search Range The following example is based on an AM-modulated signal at 100 MHz that has the following characteristics: •...

  • Page 191: Frequency Counting

    R&S ESU Brief Introduction to Remote Control Detailed Programming Examples status = viWrite(analyzer, "CALC:DELT3:X:REL?;:CALC:DELT3:Y?", 32, retCnt) 'Read delta marker 3 frequency and level; 'both must have a value of 0 status = viRead(analyzer, result$, 100, retCnt) Print "Delta 3: "; result$ REM ------ Peak search with search range limit in y direction -------------- status = viWrite(analyzer, "CALC:THR:STAT ON", 16, retCnt)

  • Page 192: Working With A Fixed Reference Point (Reference Fixed)

    Nevertheless, to measure the harmonic suppression, the level setting must be changed to higher sensitivity when measuring the harmonics, in which case it may be necessary to suppress the carrier by using a notch filter in order to prevent the RF input of the R&S ESU from being overloaded.

  • Page 193: Measuring Noise And Phase Noise

    REM ************************************************************************ Public Sub Noise() Dim status As ViStatus Dim retCnt As Long result$ = Space$(100) REM ------ Default setting of the R&S ESU ---------------------------------- Call SetupStatusReg 'Configure status register status = viWrite(analyzer, "*RST", 4, retCnt) 'Reset instrument status = viWrite(analyzer, "INST:SEL SAN", 12, retCnt) 'Change into analyzer mode.

  • Page 194: Reading Out Trace Data

    R&S ESU Brief Introduction to Remote Control Detailed Programming Examples status = viWrite(analyzer, "DISP:WIND:TRAC:Y:RLEV -20dBm", 28, retCnt) 'Reference level status = viWrite(analyzer, "INIT;*WAI", 9, retCnt) 'Perform sweep with sync REM ------ Setting the reference point ------------------------------------- status = viWrite(analyzer, "CALC:MARK:PEXC 6DB", 18, retCnt) 'Define peak excursion status = viWrite(analyzer, "CALC:MARK:STAT ON", 17, retCnt)
  • Page 195 Long, Values As Any, ByVal count As Long, retCount As Long) As Long The arrays for the measured data are dimensioned in such a way that they provide sufficient space for trace data of the R&S ESU (625 measurement points).

  • Page 196: Storing And Loading Instrument Settings

    'This subroutine selects the settings to be stored and creates the 'data record "TEST1" in the directory D:\USER\DATA. It uses the default 'setting and resets the instrument after the setting is stored. REM ------ Default settings of the R&S ESU --------------------------------- Call SetupInstrument status = viWrite(analyzer, "INIT:CONT OFF", 13, retCnt) 'Change to single sweep status = viWrite(analyzer, "INIT;*WAI", 9, retCnt)

  • Page 197: Loading Instrument Settings

    R&S ESU Brief Introduction to Remote Control Detailed Programming Examples status = viWrite(analyzer, "MMEM:COMM 'Test Setup'", 22, retCnt) REM ------ Storing on the instrument --------------------------------------- status = viWrite(analyzer, "MMEM:STOR:STAT 1,'D:\USER\DATA\TEST1'", 37, retCnt) REM ------ Resetting the instrument ---------------------------------------- status = viWrite(analyzer, "*RST", 4, retCnt)

  • Page 198: Setting The Data Record For Startup Recall

    7.2.4.3 Setting the Data Record for Startup Recall In the following example, the first step is to change the R&S ESU to the default state. In the next step, the TEST1 data record stored under D:\USER\DATA is selected for the STARTUP RECALL function, i.e.
  • Page 199 R&S ESU Brief Introduction to Remote Control Detailed Programming Examples REM ------ Default setting of the R&S ESU ---------------------------------- Call SetupStatusReg 'Configure status register status = viWrite(analyzer, "*RST", 4, retCnt) 'Reset instrument status = viWrite(analyzer, "INST:SEL SAN", 12, retCnt) 'Change into analyzer mode status = viWrite(analyzer, "INIT:CONT OFF", 13, retCnt) 'Single sweep mode...
  • Page 200 R&S ESU Brief Introduction to Remote Control Detailed Programming Examples status = viWrite(analyzer, "HCOP:IMMediate;*OPC?", 19, retCnt) 'Start printout status = viRead(analyzer, result$, 100, retCnt) REM - Printout in WMF format (BMP format) to file -------------------------- status = viWrite(analyzer, "HCOP:DEST 'MMEM'", 16, retCnt) 'Configuration: "Printout to file"...

  • Page 201: Appendix

    R&S ESU Appendix Appendix Quick Start Guide 1302.6163.62 - 04...
  • Page 202 R&S ESU Appendix Quick Start Guide 1302.6163.62 - 04...

  • Page 203: Appendix A: Printer Interface

    R&S ESU Appendix Appendix A: Printer Interface This appendix describes the installation procedure for local printers. You can either use a plug&play printer (e.g. via USB) or a non-plug&play printer (e.g. via the LPT port). To install printer drivers that are not preinstalled on the instrument, you can use one of the following external devices: LAN, USB device (e.g.

  • Page 204: Installing Usb Printers

    If you use a LAN connection for driver installation, the corresponding network drives must be mounted before starting the installation. Connect the printer via the USB connector on the front panel to the R&S ESU. The first page of the Found New Hardware Wizard dialog box is displayed.
  • Page 205 R&S ESU Appendix Installing USB Printers Click Next to get to the second Found New Hardware Wizard dialog box. Select the Install the software automatically option. The installation process runs automatically and a dialog box is displayed after the installation is completed. Proceed with step 15.
  • Page 206 Select the Install from a list or specific location option. Click Next. The third page of the wizard is displayed. Connect the USB device containing the driver to the R&S ESU (e.g. the CD-ROM drive or a memory stick) Activate the Include this location in the search option.
  • Page 207 R&S ESU Appendix Installing USB Printers Click Next. The selected folder is searched for the printer driver and the printer driver files are copied to C:. After the installation is finished, a dialog box is displayed. Quick Start Guide 1302.6163.62 - 04...

  • Page 208: Installing Non-Plug&Play Printers

    R&S ESU Appendix Installing Non-Plug&Play Printers A.2 Installing Non-Plug&Play Printers The following dialog boxes can be operated either from the front panel or via a mouse and keyboard (see sections “ Connecting a Mouse” “ Connecting an External Keyboard” on page 2.9).
  • Page 209 R&S ESU Appendix Installing Non-Plug&Play Printers To install a local printer, select Local printer attached to this computer with the rotary knob, confirm by pressing the rotary knob and continue to the next step. To install a network printer, select A network printer or a printer attached to another computer, confirm by pressing the rotary knob and continue to the next step.
  • Page 210 R&S ESU Appendix Installing Non-Plug&Play Printers In the following example, a local printer of type Star LC24 is installed. To select a USB connection, open the list of available ports by pressing the rotary knob. Using the arrow keys or rotary knob, select a printer port and confirm by pressing the rotary knob.
  • Page 211 R&S ESU Appendix Installing Non-Plug&Play Printers You can change the printer name in the Printer Name field to any name you want (max. 60 characters). However, this requires using a PC keyboard. Using the rotary knob, select Default Printer yes / no.
  • Page 212 R&S ESU Appendix Installing Non-Plug&Play Printers Check the displayed settings and exit the dialog panel with ENTER. The printer will be installed. If Windows finds the required driver files, the installation will be completed without any further queries. If Windows cannot find the required driver files, the dialog box for entering the path for files will open.
  • Page 213 R&S ESU Appendix Installing Non-Plug&Play Printers Select the path D:\I386 by turning the rotary knob and then pressing it. If the background of the selection bar is not blue, the selection must be marked with the arrow up/down keys before the entry can be selected by pressing the rotary knob.

  • Page 214: Network Printer

    R&S ESU Appendix Installing Non-Plug&Play Printers The instrument must then be configured for printout with this printer using the DEVICE SETUP and DEVICE 1/2 softkeys in the hardcopy main menu (see section “ Selecting and Configuring Printers” on page 2.27).

  • Page 215: Appendix B: External Generator Control

    R&S ESU Appendix List of Generator Types Supported by the R&S ESU Appendix B: External Generator Control B.1 List of Generator Types Supported by the R&S ESU Generator Interface Type Generator Generator Generator Generator Min. Freq. Max. Freq. Min. Power Max.
  • Page 216 R&S ESU Appendix List of Generator Types Supported by the R&S ESU Generator Interface Type Generator Generator Generator Generator Min. Freq. Max. Freq. Min. Power Max. Power SMR60B11 10 MHz 60 GHz -130 SMP02 10 MHz 20 GHz -130 SMP03...
  • Page 217 R&S ESU Index Symbols CF CARD ..........1.8 cleaning the outside ........2.8 * (enhancement label) ......4.6 CLRWR (trace mode)......4.5 color printout .........2.28 Numerics color saturation (screen) .......2.24 colors (screen) ........2.24 75 Ohm (enhancement label) ....4.6 COM............1.12 configuration different networks ......6.6 instrument ......5.34, 5.35, 5.36...
  • Page 218 R&S ESU date FILE key ..........1.5 entering..........2.20 firmware directory sharing ........6.21 installed options ........ 3.3 DISP key .......1.5, 2.22, 2.24 installing options........ 3.3 documentation overview ......0.1 uninstalling options......3.3 Operating Manual ......0.2 update ..........3.2 Quick Start Guide ......0.1 FREQ key ..........
  • Page 219 R&S ESU NETWORK........2.16 LAN ............1.17 LAN interface ..........6.1 configuring ........2.30 ID response string ........ 2.22 LIMIT CHECK (hardware setting) ...4.3 IF OUT 20.4 MHz ......... 1.16 LINES key ..........1.5 IFOVL (status display) ......4.4 login installation in a 19" rack......2.5 automatic login mechanism .....6.14...
  • Page 220 R&S ESU MONITOR ........1.13, 2.12 installing ..........3.3 monitor uninstalling ........3.3 connecting ........2.12 OVEN (status display) ......4.4 MOUSE........1.13, 2.11 OVLD (status display)......4.4 mouse connecting ........2.11 supported devices ......2.11 PA (enhancement label) ......4.6 parameter alphanumeric........4.9 network editing.........
  • Page 221 R&S ESU QP (detector) .......... 4.5 SA (detector) ...........4.5 screen automatically switching off ....2.24 brightness ........2.23 RBW (hardware setting) ......4.3 color saturation ........2.24 colors ..........2.24 rear panel ..........1.10 displays..........4.3 connectors........1.12 recall function ......... 2.6 layout during analyzer operation..4.2 tint ............2.23...
  • Page 222 R&S ESU REFERENCE INT/EXT....2.19 MAXH ..........4.5 REMOVE OPTION ......3.3 MI ............4.5 RESTORE FIRMWARE.....3.2 MINH ..........4.5 SATURATION .........2.24 PK ............. 4.5 SCREEN COLORS ......2.28 QP ............. 4.5 SELECT OBJECT ......2.23 RM............. 4.5 TIME+DATE ........2.19 SA ............. 4.5 TINT..........2.23 trace mathematics ......
  • Page 223 R&S ESU administrator ID...... 2.35, 2.36 approved software......2.36 Firewall..........6.8 login..........2.35 password......... 2.35 service pack ........2.36 Start menu........2.36 XP Remote Desktop ......6.24 connection........6.34 connection setup ......6.30 controller configuration....6.27 instrument configuration....6.24 instrument deactivation ....6.35...

Table of Contents
