R&S ESR Series User Manual page 800

®
R&S ESR
y-axis upper limit:
y-axis lower limit:
Suffix:
<n>
Example:
Manual operation:
CALCulate<n>:STATistics:SCALe:AUTO ONCE
This command optimizes the level setting of the instrument depending on the mea-
sured peak power, in order to obtain maximum instrument sensitivity.
To obtain maximum resolution, the level range is set as a function of the measured
spacing between peak power and the minimum power for the APD measurement and
of the spacing between peak power and mean power for the CCDF measurement. In
addition, the probability scale for the number of test points is adapted.
Subsequent commands have to be synchronized with *WAI, *OPC or *OPC? to the
end of the auto range process which would otherwise be aborted.
Suffix:
<n>
Example:
Manual operation:
CALCulate<n>:STATistics:SCALe:X:RANGe <Value>
This command defines the level range for the x-axis of the measurement diagram. The
setting is identical to the level range setting defined with the
WINDow<n>]:TRACe<t>:Y[:SCALe]
Suffix:
<n>
Parameters:
<Value>
Example:
Manual operation:
User Manual 1175.7068.02 ─ 12
Remote Commands in Spectrum Analyzer Mode
.
irrelevant
CALC:STAT:PRES
Resets the scaling for statistical functions
See "Default Settings"
.
irrelevant
CALC:STAT:SCAL:AUTO ONCE;*WAI
Adapts the level setting for statistical measurements.
See "Adjust Settings" on page 320
command.
.
irrelevant
10dB to 200dB
*RST: 100dB
CALC:STAT:SCAL:X:RANG 20dB
See "x-Axis Range" on page 317
1.0
1E-6
on page 319
DISPlay[:
Remote Control
797
