R&S ESR
Parameters:
<Delay>
Example:
Manual operation:
TRIGger<n>[:SEQuence]:IFPower:HOLDoff <Value>
This command sets the holding time before the next IF power trigger event.
Note: Using gating with gate mode "level" (see
on page 897) and an IFP trigger (see
on page 838), the holdoff time for the IFP trigger is ignored for frequency sweep, FFT
sweep, zero span and IQ mode measurements.
Suffix:
<n>
Parameters:
<Value>
Example:
Manual operation:
TRIGger<n>[:SEQuence]:IFPower:HYSTeresis <Value>
This command sets the limit that the hysteresis value for the IF power trigger has to fall
below in order to trigger the next measurement.
Suffix:
<n>
Parameters:
<Value>
Example:
Manual operation:
TRIGger<n>[:SEQuence]:LEVel[:EXTernal] <TriggerLevel>
This command sets the level of the external trigger source in Volt.
User Manual 1175.7068.02 ─ 12
Remote Commands in Spectrum Analyzer Mode
Range: zero span: -sweeptime (see data sheet) to 30 s;
span: 0 to 30 s
*RST: 0 s
TRIG:HOLD 500us
See "Trigger Offset" on page 378
TRIGger<n>[:SEQuence]:LEVel:IFPower
.
irrelevant
*RST: 150 ns
TRIG:SOUR IFP
Sets the IF power trigger source.
TRIG:IFP:HOLD 200 ns
Sets the holding time to 200 ns.
See "Trigger Holdoff" on page 378
.
irrelevant
*RST: 3 dB
TRIG:SOUR IFP
Sets the IF power trigger source.
TRIG:IFP:HYST 10DB
Sets the hysteresis limit value.
See "Trigger Hysteresis"
Remote Control
TRACe<n>:IQ:EGATe:TYPE
on page 378
