9. TRIMMER SECTION
9.2

Drive

9.2.1

Trimmer press drive

[3]
[1] Trimmer board
[2] Press arm
[3] Trimmer press motor (M32)
[4] Slide block
108
Theory of Operation Ver2.0 Sep.2006
[4] [5]
[2]
[5] Press drive screw
[6] Trimmer press home sensor (PS53)
[7] Trimmer press upper limit sensor (PS52)
[8] Trimmer press plate
[6] [7] [8]
[1]
15ant2c067na
