Develop ineo+ 6500 Service Manual page 38

Theory of Operation Ver1.0 Sep.2006
F. Machine data
Power source
Maximum power consump-
tion
Dimensions
Weight
G. Operating environment
Temperature
Humidity
Note
• The information herein may be subject to change for improvement without notice.
Inch: AC208 to 240V 16A, 60Hz
Metric: AC230V 15A, 50Hz
Inch: 4,550W or less (B. When the type of the optional unit connection con-
figuration (P2) is No. 9)
3,950W or less (B. When the type of the optional unit connection con-
figuration (P2) is No. 10)
Metric: 4,060W or less (B. When the type of the optional unit connection con-
figuration (P2) is No. 9)
3,550W or less (B. When the type of the optional unit connection con-
figuration (P2) is No. 10)
Main body + OC- 786 (W) x 992 (D) x 1,056 (H) mm
506
Main body + DF- 3,852 (W) x 992 (D) x 1,414 (H) mm
609 + RU-503
+ LS-501
+ SD-501
Approx. 360kg
10 to 30 °C
10 to 80%RH (with no condensation)
2. PRODUCT SPECIFICATIONS
7
