Bundle Exit Drive - Develop ineo+ 6500 Service Manual

Theory of Operation Ver2.0 Sep.2006
8.2.5

Bundle exit drive

[13]
[12]
[11]
[10]
[9]
[8]
[7]
[1] Bundle exit conveyance belt
[2] Left side view
[3] Bundle exit drive belt
[4] Actuator
[5] Belt
[6] Bundle exit motor (M5)
[7] One-way clutch (for the bundle exit convey-
ance belt)
[6] [5] [4]
[8] Trimmer scraps press plate
[9] Pin
[10]
[11]
[12]
[13]
8. BUNDLE PROCESSING SECTION
[3]
Trimmer scraps press claws
Scraps press home sensor (PS48)
Shutter
One-way clutch (for pressing the trimmer
scraps)
[1]
[2]
15ant2c055nb
