Theory of Operation Ver2.0 Sep.2006
5.2
Drive
5.2.1
Right angle conveyance drive/alignment drive
[6]
[1]
Alignment claws
[2]
Torque limiter
[3]
Roller release solenoid /1 (SD5)
[4]
Front side direction
[5]
Top side view
[6]
Roller release solenoid /2 (SD6)
[11]
[10]
[9]
[7]
[8]
[5]
5. RIGHT ANGLE CONVEYANCE SECTION
[7]
Right angle conveyance roller /4
[8]
Right angle conveyance roller /3
[9]
Right angle conveyance roller /2
[10]
Right angle conveyance motor (M6)
[11]
Right angle conveyance roller /1
[1]
[2]
[3]
[4]
