Develop ineo+ 6500 Service Manual page 278

Theory of Operation Ver1.0 Sep.2006
[6]
[5]
[4]
[3]
[4]
[19]
[1] Decurler gate solenoid /1 (SD2) ON
[2] Decurler gate solenoid /1 (SD2)
[3] Switching paper through path
[4] Paper through path (normal path)
[5] Paper through path (toward the decurler /
Up)
[6] The paper curled upward
[7] Decurler belt /1
[8] Decurler roller /2
[9] Decurler /Up
[10] Decurler belt /2
[16]
[14]
[17]
[18]
4. CONVEYANCE SECTION
[13]
[11] Decurler /Lw
[12] Decurler roller /4
[13] Paper exit sensor (PS3)
[14] Decurler roller /2
[15] Decurler roller /3
[16] The paper curled downward
[17] Paper through path (toward the decurler /
Lw)
[18] Decurler gate solenoid /2 (SD3)
[19] Decurler gate solenoid /2 (SD3) ON
[1]
[2]
[3]
[8]
[9]
[10]
[11]
[12]
