Product Specifications - Develop ineo+ 6500 Service Manual

Theory of Operation Ver1.0 Sep.2006
OUTLINE

1. PRODUCT SPECIFICATIONS

1.1 LU-202
A. Type
Type
B. Functions
Max. tray capacity
*1 Stacked height 275 mm
C. Paper type
Paper size
Applicable paper
*1 Available types of paper weighing 300 g/m
D. Maintenance
Maintenance
Machine service life
E. Machine data
Power source
Maximum power consump-
tion
Weight
Dimensions
F. Operating environment
Temperature
Humidity
Side mount type large volume paper feed tray
2 *1
2500 sheets (80 g/m )
SRA3, A3, B4, SRA4, SRA4S, A4, A4S, B5
13 x 19, 12 x 18, 11 x 17, 8
8K, 16K
Tab paper (A4, 8 / x 11)
1
2
Custom paper (Max. 330 x 487mm, Min. 210 x 182 mm)
Plain paper, high quality paper, coated paper
2 *1
64 to 300 g/m
2
are limited to specific types.
Same as the main body.
Same as the main body.
24/12/5VDC, 200 to 240VAC (supplied both from the main body)
DC: 40W or less, AC: 50W or less (not including HT-503)
Approx. 40kg
710 (W) x 639 (D) x 477 (H) mm
10 to 30°C
10 to 80% RH (with no condensation)
1. PRODUCT SPECIFICATIONS
/ x 14, 8 / x 11, 8 / x 11S
1 1 1
2 2 2
*1
1
