Trimmer Blade Drive - Develop ineo+ 6500 Service Manual

Theory of Operation Ver2.0 Sep.2006
9.2.2

Trimmer blade drive

[1] Trimmer blade drive screw
[2] Drive plate
[3] Drive guide holes
[4] Drive shafts
[5]
[4] [3]
[6] [7] [8]
[2]
[5] Trimmer blade
[6] Trimmer blade home sensor (PS50)
[7] Trimmer blade upper limit sensor (PS51)
[8] Trimmer blade motor (M31)
9. TRIMMER SECTION
[1]
15ant2c068na
109
