4. PAPER FEED SECTION
4.2

Drive

4.2.1

Paper feed drive

[8]
[9]
[1] Paper feed motor (M1)
[2] Paper feed clutch (MC101)
[3] Pick-up roller
[4] Paper feed roller
[5] One-way mechanism
6
[9]
[6]
[7]
Theory of Operation Ver1.0 Sep.2006
[10]
[5]
[3]
[4]
[6] Separation roller
[7] Front side
[8] Torque limitter
[9] Pre-registration roller
[10] Pre-registration clutch (MC102)
[1]
[2]
a03wt2c002ca
