Theory of Operation Ver2.0 Sep.2006
OUTLINE

1. PRODUCT SPECIFICATIONS

A. Type
Type
Conveyance method
Alignment method
Method of stacking
Shifting method
B. Functions
Mode
Maximum number of
sheets loadable
Grip conveyance type horizontal stacker
Entrance convey- Roller conveyance method
ance
Stacker tray con- Grip conveyance method
veyance
Sub tray convey- Roller conveyance method
ance
Coupling convey- Roller conveyance (LS-501 only)
ance
Movable alignment lever (stacker tray only)
Horizontal stack- Mixing of original sizes not allowed (stacker tray only)
ing
Conveyance Shift amount: 20 mm (stacker tray only)
direction shift
Stacker tray non- Exited into the stacker tray with no processing made.
sort mode
Sub tray mode Exited into the sub tray with no processing made.
Stacker tray sort Exited into the stacker tray after being shifted (20mm).
mode
Coupling mode Exited into the post-processing unit with no processing
made.
Stacker tray 5,000 sheets (80 g/m
Sub tray 200 sheets (80 g/m
