6.12 Toner collection (Sub step 5)

The toner removed from the drums and the transfer belt is collected to the toner collection box through the toner
collection screw.
[2]
[1] Toner collection box
[2] Toner collecting port (Transfer belt)
[3] Toner collecting port (Drum/Y)
[3]
[4]
[5]
[6]
[4] Toner collecting port (Drum/M)
[5] Toner collecting port (Drum/C)
[6] Toner collecting port (Drum/K)
6. IMAGE CREATING PROCESS
[1]
