Theory of Operation Ver1.0 Sep.2006

5. CONVEYANCE SECTION

5.1

Configuration

Vertical conveyance roller/1
Horizontal conveyance
roller/2
Multi feed
detection board
/R (MFDTB/R),
/S (MFDTB/S)
Centering sen-
sor (PS25)
Vertical conveyance
roller/2
Vertical conveyance
roller/3
Small size roller
Horizontal conveyance roller/1
Pre-registration roller
5. CONVEYANCE SECTION
a03xt2c014ca
19
