14. TONER COLLECTION SECTION
14. TONER COLLECTION SECTION
14.1 Configuration
Belt collection pipe
Vertical conveyance pipe
Waste toner full sensor (PS52)
62
Belt waste toner socket
Drum /Y waste toner socket
Drum /M waste toner socket
Drum /C waste toner socket
Drum /K waste toner socket
Horizontal con-
veyance pipe
Theory of Operation Ver1.0 Sep.2006
Waste toner door sensor (PS60)
Waste toner outlet
Toner collection box
a03ut2c043ca
