6. CONVEYANCE SECTION
(1) Stacker tray non-sort mode
Ex.: Letter 4 sheets
Entrance sensor (PS4)
Latch ON signal
Job partition
solenoid (SD2)
Latch OFF signal
[1] Main body paper exit sensor (PS3) ON
[2] 1st sheet of paper
[3] Job partition plate close
[4] 2nd sheet of paper
[5] Job partition plate close
(2) Stacker tray sort mode
Ex.: Letter 2 sheets
Entrance sensor (PS4)
Latch ON signal
Job partition
solenoid (SD2)
Latch OFF signal
[1] Main body paper exit sensor (PS3) ON
[2] 1st sheet of shift paper
[3] Job partition plate open (shift amount: 20 mm)
[4] 2nd sheet of shift paper
26
[1] [2]
[1] [2]
[3]
Theory of Operation Ver2.0 Sep.2006
[4] [6]
[3] [5] [7]
[6] 3rd sheet of paper
[7] Job partition plate close
[8] Last sheet of paper
[9] Job partition plate close
[4] [5]
[6]
[5] 1st sheet of non-shift paper
[6] Job partition plate close
[7] 2nd sheet of non-shift paper
[8] Job partition plate close
[8]
[9]
ls502to2021c
[7]
[8]
ls502to2022c
