Theory of Operation Ver1.0 Sep.2006
B. Reverse paper exit mode
• Each control timing is the same as in the straight mode.
Entrance sensor (PS1)
Entrance
conveyance motor
(M1)
Paper exit motor
(M5)
[1] Start-printing signal ON
[2] Paper leading edge detection
[3] Paper trailing edge detection
[1] [2] [3]
Middle
Low
High
Middle
Low
(speed)
[4] [5]
4. CONVEYANCE SECTION
[4] Decelerating at middle speed
[5] Accelerating at high speed
a04kt2c005ca
11
