Develop ineo+ 6500 Service Manual page 531

3. PAPER PATH
B. Multi letter folding mode
[4] [5]
[3]
[1] Stack to the right angle conveyance section
[2] Right angle conveyance
[3] Conveyance to the folding section
[4] 1st folding
[5] 2nd folding
10
[7] [6]
[10]
Theory of Operation Ver2.0 Sep.2006
[2]
[6] Paper exit
[7] Stack movement of the paper exit
[8] Front side view
[9] Top side view
[10] Right side view
[1]
[8]
[9]
15ant1c003na
