1. PRODUCT SPECIFICATIONS
1.2 HT-504
A. Type
Type
B. Maintenance
Machine service life
C. Machine data
Power source
Maximum power consump-
tion
Dimensions
Weight
*1 North America model: Supplied from the main body.
Europe model:
D. Operating environment
Temperature
Humidity
2
Fan heater type dehumidifier heater
Same as the main body.
24/5VDC (supplied from the main body), 200 to 240VAC
DC: 6W or less, AC: 580W or less
Dehumidifier fan heater unit: 197 (W) x 82 (D) x 293 (H) mm
Power supply unit: 121 (W) x 80 (D) x 160 (H) mm
Dehumidifier fan heater unit: Approx. 1.5kg/1 unit
Power supply unit: Approx. 0.9kg
Supplied from external.
10 to 30°C
10 to 80%RH (with no condensation)
Theory of Operation Ver1.0 Sep.2006
*1
