Product Specifications - Develop ineo+ 6500 Service Manual

Theory of Operation Ver1.0 Sep.2006
OUTLINE

1. PRODUCT SPECIFICATIONS

A. Type
Type
B. Functions
(1) Functions
Non-sort mode
Sort/group mode
Sub tray mode
Stapling mode
Saddle stitching mode
Folding mode
Tri-folding mode
(2) Stapling
Max. flat-stapling capacity
Max. saddle stitching
capacity
(3) Folding
Max.Folding
Max.Tri-folding
Multi folding multi stapling device
Exited to the main tray with no processing made.
Exited to the main tray after being shifted for every copy.
Exited to the sub tray with no processing made.
Exited to the main tray after being stapled.
Exited to the booklet tray with the paper folded into two after being stitched and
folded at the center of the paper.
Exited to the booklet tray with the paper folded into two at its center.
Exited to the booklet tray after being overlapped up to 3 sheets and being tri-
folded.
50 sheets of 64 to 80 g/m
paper, coated paper)
30 sheets of 81 to 105 g/m
paper, coated paper)
Up to 2 sheets of 200g/m2 can be added unless the total number of sheets
exceeds the above capacity.
staple position Front parallel / back 45° 1 position diagonally, 2 positions
at the center
2
20 sheets of 64 to 80 g/m
20 sheets of 81 to 105 g/m
paper, coated paper)
Up to 2 sheets of 200g/m2 can be added unless the total number of sheets
exceeds the above capacity.
staple position variable (128 to 168mm)
2
3 sheets of 64 to 105 g/m
2
3 sheets of 64 to 80 g/m
2
1 sheet of 81 to 105 g/m
1. PRODUCT SPECIFICATIONS
2
(plain paper, high-quality paper),30 sheets (color
2
(plain paper, high-quality paper),16 sheets (color
2
(Plain paper, high-quality paper), 16 sheets (color
paper
paper
paper
1
