3. PAPER PATH
C. Punch mode (L and S sizes)
[1] Paper through from the PI
[2] Paper through from the main body paper exit
[3] In the case of a L size
[4] In the case of a S size
8
[6]
[5]
[4]
[3]
Theory of Operation Ver2.0 Sep.2006
[5] Paper exit to the main tray, paper through to
the next option
[6] Paper exit to the sub tray
[1]
[2]
fd501to1004c
